Schneider Electric Molded Case Circuit Breaker 3-Pole 50A 690V AC Breaking Capacity 70 kA Compact NSXm LV426504
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426504 |
| Depth | 80mm |
| Width | 81mm |
| Mount Type | Clip-on |
| Current Rating | 50A |
| Series | Compact NSXm |
| Terminal type | Screw |
| Breaking Capacity | 70kA |
| Number of Poles | 3 |
| Standards/Approvals | RoHS, EN, IEC, CCC, CE, EAC |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- This circuit breaker features a compact NSXm series design suited for heavy-duty applications.
- It offers three poles with a current rating of 50 amperes for optimal circuit protection.
- Thermal magnetic tripping mechanism ensures reliable and fast disconnection under overload conditions.
- Type D tripping characteristics provide higher tolerance to inrush currents typical in motor starting.
- Mount type is clip-on, facilitating easy installation and replacement in electrical panels.
- Reset actuator is a toggle switch for straightforward manual control.
- Terminals use screw type connections for secure wiring.
- Conforms to multiple standards including RoHS, EN, IEC, CCC, CE, and EAC for quality assurance.
Product Description
Schneider Electric LV426504 Molded Case Circuit Breaker from the Compact NSXm series is a high-performance electrical protection device designed to safeguard electrical circuits in various industrial and commercial applications. Rated for a 690V AC supply, this 3-pole circuit breaker has a robust current rating of 50 amperes and a high breaking capacity of 70 kA, ensuring reliable interruption of fault currents and protection against overloads and short circuits.
The device integrates a thermal magnetic tripping mechanism with Type D tripping characteristics, which provides enhanced tolerance for inrush currents commonly experienced in motor starting and other inductive loads. Installation is simplified through its clip-on mount type and screw terminal connections, allowing secure and fast panel integration and maintenance.
With dimensions of 137 mm in height, 81 mm in width, and 80 mm in depth, the compact form factor eases incorporation into electrical distribution boards without occupying excessive space. The toggle switch actuator enables straightforward manual resetting after trip events.
This circuit breaker meets stringent international standards including RoHS and IEC certifications, underscoring its compliance with safety, environmental, and quality requirements. It is suitable for applications within industrial manufacturing plants, commercial buildings, and electrical automation systems.
This Compact NSXm series breaker provides dependable circuit protection with a 50A current rating. Breaking capacity of 70 kA at 690V AC ensures interruption of high fault currents. Thermal magnetic tripping with Type D characteristic enhances protection in motor circuits.
Clip-on mounting and screw terminal design allow quick installation and maintenance. Compact dimensions support space-saving panel configurations. Toggle switch actuator supports easy manual operation for reset. Meets multiple international safety and quality standards including RoHS and IEC.
Applicable in industrial, commercial, and manufacturing electrical distribution. Explore more Schneider Electric Circuit Breakers and related electrical components in the Electronics & Electricals category at EnvMart for your automation and protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Schneider Electric Molded Case Circuit Breaker has a breaking capacity of 70 kA at 690V AC, ensuring reliable interruption of fault currents.
This model has a current rating of 50 amperes, providing optimal circuit protection for various applications.
It features three poles, which allows for effective circuit protection in three-phase systems.
The circuit breaker utilizes a thermal magnetic tripping mechanism, which ensures reliable and fast disconnection under overload conditions.
The dimensions of this unit are 137 mm in height, 81 mm in width, and 80 mm in depth, making it compact for installation in electrical panels.
This circuit breaker has a clip-on mount type, facilitating easy installation and replacement in electrical panels.
It features screw type connections for secure wiring, ensuring a reliable electrical connection.
It has Type D tripping characteristics, which provide higher tolerance to inrush currents, making it suitable for motor starting applications.
This model conforms to multiple standards including RoHS, EN, IEC, CCC, CE, and EAC, ensuring compliance with safety and quality requirements.
The reset actuator is a toggle switch, allowing for straightforward manual control after a trip event.
It is suitable for applications within industrial manufacturing plants, commercial buildings, and electrical automation systems.
This model belongs to the Compact NSXm series, known for its high-performance electrical protection capabilities.
