ABB Residual Current Circuit Breaker 40A 4-Pole 30 mA Type A 1 kA Breaking Capacity 480V 2CSF204199R1400 F204 A-40/0,03 110V

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Circuit Breaker 40A 4-Pole 30 mA Type A 1 kA Breaking Capacity 480V 2CSF204199R1400 F204 A-40/0,03 110V



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	F200
Brand	ABB
Height	85mm
Model	2CSF204199R1400 F204 A-40/0,03 110V
Depth	69mm
Width	70mm
Mount Type	DIN Rail
Current Rating	40A
Series	F200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	4
Standards/Approvals	RoHS, IEC EN 61008, CE
Rated AC Voltage	480V ac
Tripping Characteristics	Type A
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

The device has a current rating of 40A for robust electrical load handling.
It features a 4-pole configuration to ensure comprehensive circuit protection.
The trip sensitivity is set at 30 mA to effectively detect leakage currents.
The tripping characteristic is Type A for both alternating and pulsating DC residual currents.
Breaking capacity of 1 kA ensures safety during fault conditions.
Mounting is on standard DIN rails for easy installation.
Equipped with a toggle switch reset actuator for user convenience.
Electromagnetic tripping mechanism provides fast and accurate response.

Product Description

ABB 2CSF204199R1400 F204 A-40/0,03 110V Residual Current Circuit Breaker from the F200 Series is designed to protect electrical installations from earth leakage currents, ensuring safety in residential, commercial, and industrial environments.

This RCCB has a rated current of 40 Amperes and operates on a 4-pole system offering comprehensive protection. It features a trip sensitivity of 30 mA and Type A tripping characteristics that protect against alternating sinusoidal and pulsating direct residual currents.

The unit is suitable for 480V AC rated voltage and has a breaking capacity of 1 kiloampere to safely interrupt fault currents. The instantaneous electromagnetic tripping mechanism allows for rapid disconnection in fault conditions. Mounting is easily facilitated on DIN rails with screw terminals ensuring secure connections.

The device includes a toggle switch type reset actuator for straightforward manual reset and compact dimensions (85mm height, 70mm width, 69mm depth) that accommodate most electrical panels.

This Residual Current Circuit Breaker complies with international standards RoHS, IEC EN 61008, and CE, and is made in Italy, reflecting high manufacturing quality and reliability. Typical applications include residential housing, commercial buildings, and industrial installations requiring sensitive earth leakage protection.

The device has a current rating of 40A for robust electrical load handling. It features a 4-pole configuration to ensure comprehensive circuit protection. The trip sensitivity is set at 30 mA to effectively detect leakage currents.

The tripping characteristic is Type A for both alternating and pulsating DC residual currents. Breaking capacity of 1 kA ensures safety during fault conditions. Mounting is on standard DIN rails for easy installation. Equipped with a toggle switch reset actuator for user convenience.

Compact dimensions: Height 85mm, Width 70mm, Depth 69mm. Electromagnetic tripping mechanism provides fast and accurate response. Terminal type uses screws for secure wiring connections. Discover a full range of ABB circuit breakers and electrical protection devices at EnvMart for industrial automation, construction, and electric utility applications.
