ITT Cannon Industrial Circular Connector 19 Contacts Cable Mount Plug Female IP67 Nylon Housing TN6S16-0019S2L / 192900-0558
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 25.0V |
| Brand | ITT Cannon |
| Orientation | Straight |
| Current | 30A |
| Model | TN6S16-0019S2L / 192900-0558 |
| IP Rating | IP67 |
| Mount Type | Cable |
| Housing Material | Nylon |
| Contact Material | Copper |
| Series | Trident Neptune |
| Termination Type | Crimp |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pole Format | 19 |
| Contact Plating | Nickel |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Shell Size | 16 mm |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Plug/Socket | Plug |
Key Features
- Designed for industrial and outdoor electronics applications.
- Features a robust bayonet mating type ensuring secure connections.
- Supports 30A current at 25V voltage rating.
- Plastic coupling ring provides corrosion resistance.
- Operates reliably between -55°C to 105°C temperature range.
- Connector size is standard with 16 mm shell size.
- Contact plating is nickel with copper contact material for durability.
- Termination type is crimp ensuring reliable wire attachment.
Product Description
ITT Cannon TN6S16-0019S2L / 192900-0558 industrial circular connector is a cable mount plug designed for harsh environment applications requiring high reliability and corrosion resistance. It features 19 contacts arranged in a standard connector size with a 16 mm shell size and bayonet type mating mechanism to ensure firm and quick connections.
This connector supports a maximum current rating of 30A and operates at 25V, withstanding minimum and maximum operating temperatures ranging from -55°C to 105°C. The housing is made of rugged nylon material combined with a plastic coupling ring that enhances corrosion resistance and long service life under demanding outdoor and automotive environments.
The female contact gender of this plug is fitted with nickel-plated copper contacts, providing excellent conductivity and durability. Termination is by crimp style, which facilitates secure and reliable wire connections. The Trident Neptune series offers combined power and signal contacts, ideal for industrial, marine, automotive, and process control applications.
To achieve IP67 ingress protection, the connector incorporates a rubber seal at the rear, pierced by contact insertion, held in place by a screw ring. This seal safeguards against dust and water ingress, making it suitable for outdoor and environmentally challenging conditions.
Robust bayonet coupling system providing secure connections. Corrosion resistant nylon housing and plastic coupling ring. High current (30A) and voltage (25V) ratings for demanding industrial use. Wide operating temperature range from -55°C to 105°C.
Nickel-plated copper contacts ensuring electrical reliability. Crimp termination for secure wire attachment. IP67 rated for protection against dust and water ingress. Ideal for automotive, marine, and process control environments.
Trident Neptune series combining power and signal contacts. Standard size connector with 19 contact poles and 16 mm shell size.
This connector flushes with EnvMart’s Industrial Circular Connector category for electronic components that demand high durability, environmental resistance, and precise connectivity across multiple industrial sectors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 30A and operates at 25V.
It operates reliably within a temperature range of -55°C to 105°C.
The connector features 19 contacts arranged in a standard configuration.
Termination for this unit is by crimp style, ensuring secure wire attachment.
The housing is made of nylon, and the contacts are nickel-plated copper for conductivity and durability.
It has an IP67 rating, providing protection against dust and water ingress.
It features a robust bayonet mating type, ensuring secure and quick connections.
The connector has a standard shell size of 16 mm.
This connector is suitable for industrial, marine, automotive, and process control applications.
The orientation of this model is straight.
The country of origin for this connector is India.
This connector is part of the Trident Neptune series, which combines power and signal contacts.
