Hirose DF13 Series Straight Surface PCB Header, 4 Contacts, 1.25 mm Pitch, 1 Row, Shrouded DF13
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 1A |
| Model | DF13 |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | DF13 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -35°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Standards/Approvals | IEC, RoHS |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Cable |
| Tail Pin Length | 1.5mm |
Key Features
- Operates at a maximum voltage of 500V and rated current of 1A.
- Constructed with a polyamide housing and brass contacts plated with tin for durability.
- Designed for surface mount with a tail pin length of 1.5 mm ensuring secure soldering.
- Operates reliably between temperatures -35°C to 85°C.
- Shrouded design prevents mis-insertion and supports automatic mounting.
- Compact miniature size with low profile mounting height of 5.8 mm for space saving applications.
- Complies with IEC and RoHS standards for safety and environmental compliance.
- Suitable for various consumer electronics including PC, mobile terminals, and video camera equipment.
Product Description
Hirose DF13 series straight surface PCB header, model DF13, is engineered for high reliability in electronic connector applications. This 4-contact connector features a 1.25 mm pitch and a single-row, shrouded configuration ideal for board-to-cable connections using surface mounting technology.
The housing is made of durable polyamide, while the contacts use brass with tin plating for excellent conductivity and corrosion resistance. Operating voltage reaches up to 500V with a rated current of 1A, suitable for low-power signal connections.
This PCB header supports a temperature range from -35°C to 85°C, making it usable in a broad variety of industrial and consumer electronic environments. The termination type is solder with a tail pin length of 1.5 mm designed for optimal soldering quality.
The miniature size with a mounting height of 5.8 mm supports compact PCB layouts typical in mobile and miniature devices. The scoop-proof box structure and shrouded design prevent connector mis-insertion and ensure secure connections. Additionally, automatic mounting is facilitated by embossing tape packaging designed for vacuum absorption pick-and-place processes.
Maximum voltage rating of 500V and current rating of 1A. Polyamide housing with brass/tin-plated contacts. Surface mount type with 1.5 mm tail pin length. Operating temperature range from -35°C to 85°C. Shrouded, single-row design for secure insertion.
Compliant with IEC and RoHS standards. Miniature low-profile design suitable for consumer electronics.
Widely used across electronic components manufacturing, including in PC peripherals, mobile devices, video cameras, and other portable electronics. Designed and manufactured in Japan, ensuring high quality and reliability standards.
Explore more products in the PCB Header category for comprehensive connectivity solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating of this PCB header is 500V.
The rated current for this connector is 1A.
The housing is made of polyamide, and the contacts are brass plated with tin.
It operates reliably between -35°C and 85°C.
This connector features 4 contacts.
The pitch size of this PCB header is 1.25 mm.
This model uses a solder termination type.
Yes, it complies with IEC and RoHS standards for safety and environmental compliance.
The tail pin length is 1.5 mm, designed for optimal soldering quality.
This model supports surface mounting.
The shrouded design of this connector prevents mis-insertion and supports automatic mounting.
This PCB header is manufactured in Japan.
