Microchip EVB-USB4715 USB Smart Hub Evaluation Kit, 25 MHz, USB 2.0 Interface EVB-USB4715

Microchip EVB-USB4715 USB Smart Hub Evaluation Kit EVB-USB4715 provides a practical and versatile platform for evaluating the USB4715 chip, a high-speed 4-port USB smart hub. Featuring a 25 MHz maximum frequency USB 2.0 interface, this evaluation kit assists engineers and developers in gaining practical insights into the device’s operation and integrating it into their applications.

The evaluation board is built on a 4-layer Printed Circuit Board (PCB) to ensure signal integrity and robust performance during testing. It supports USB 2.0 High-Speed (HS), Full-Speed (FS), and Low-Speed (LS) signalling, making it adaptable for diverse USB communication needs.

This kit is equipped with four downstream USB ports, including two Type-A USB 2.0-only and two Type-C USB 2.0 ports for versatile connectivity options. Additionally, it includes a USB 2.0 micro-AB upstream port. The USB pins are designed to be 5V tolerant, enhancing device durability in various circuit conditions.

Microchip’s proprietary PortSwap, PHYBoost™, and VariSense™ technologies are integrated into the evaluation kit, providing users with advanced features for testing signal quality, power management, and data integrity.

The on-board 25 MHz crystal oscillator or option for an external clock input provides precise timing sources essential for USB communication. The kit operates in self-powered mode and includes a 12V power supply and USB cable in the package for immediate use.

The USB4715 is housed in a compact 48-pin QFN package, facilitating easy handling and mounting. The kit complies with several industry standards including RoHS2 Directive 2011/65/EU, FCC regulations, ISO/TS-16949:2009, R&TTE Directive 1999/5/EC, and ISO 9001:2000 quality standards.

This evaluation kit is ideal for industrial, communication, electronics development, laboratory testing, manufacturing prototyping, and educational purposes requiring USB hub functionality testing and integration.

Enables comprehensive evaluation of USB4715, a 4-port high-speed USB smart hub. Includes on-board 25 MHz crystal oscillator or external clock input for flexible timing. Features four downstream USB ports supporting Type-A and Type-C connectors.

Supports USB 2.0 High-Speed, Full-Speed, and Low-Speed signalling standards. Offers self-powered operation with included 12V power supply and USB cable. USB pins are 5V tolerant providing robust electrical compatibility.

Compact 48-pin QFN package allows easy integration into designs. Designed to accelerate USB4715 integration and prototyping processes. Complies with multiple standards including RoHS2, FCC, ISO/TS-16949, R&TTE, and ISO 9001:2000.
