Molex KK 396 Series Straight Through Hole Pin Header 24 Contacts 3.96 mm Pitch 1 Row Unshrouded 26-48-1241
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 4.37mm |
| Mating Pin Length | 11.43mm |
Key Features
- Features 24 male contacts arranged in a single row for optimal connectivity.
- Constructed with polyester housing material ensuring durability.
- Contacts are made of brass and plated with tin for reliable conductivity.
- Designed for through-hole mounting providing secure attachment to PCB.
- Operates safely within a temperature range of -40°C to 105°C.
- Supports a current rating of 7A and voltage rating of 250V.
- Unshrouded design facilitates easy access and insertion.
- Tail pin length is 4.37 mm with mating pin length of 11.43 mm.
Product Description
Molex 26-48-1241 KK 396 Series Straight Through Hole Pin Header offers robust board connection solutions with 24 male contacts in a single row spaced at 3.96 mm pitch. The connector is manufactured with a durable polyester housing and brass contacts plated with tin, ensuring efficient electrical performance and corrosion resistance.
Designed for through-hole mounting, it provides reliable mechanical and electrical connections ideal for board-to-board and wire-to-board systems in industrial, electronics manufacturing, and commercial electrical equipment.
This connector supports current ratings of up to 7A and a maximum voltage of 250V, making it suitable for moderate power signal transmission. Its unshrouded pin configuration allows easy access during assembly and maintenance. The product operates effectively across a wide temperature range from -40°C to 105°C, suitable for varied environmental conditions.
The precise tail pin length of 4.37 mm and mating pin length of 11.43 mm guarantee stable and accurate insertion into PCB sockets. The KK 396 Series meets industry standard dimensions and mechanical specifications, enhancing compatibility with numerous PCB header systems.
Features 24 male contacts arranged in a single row for optimal connectivity. Constructed with polyester housing material ensuring durability. Contacts are made of brass and plated with tin for reliable conductivity. Designed for through-hole mounting providing secure attachment to PCB.
Operates safely within a temperature range of -40°C to 105°C. Supports a current rating of 7A and voltage rating of 250V. Unshrouded design facilitates easy access and insertion. Tail pin length is 4.37 mm with mating pin length of 11.43 mm.
Industry standard 3.96 mm row pitch for compatibility.
This Molex KK 396 Series Pin Header is commonly used in electronic components assembly, industrial automation, communications equipment, and prototyping applications. Its consistent build quality ensures longevity and reliability in demanding electrical environments.
Explore the Electronics Components category at EnvMart for a wide selection of PCB Headers and connectors tailored to your requirements.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 3.96 mm, which is standard for compatibility with various PCB header systems.
It features 24 male contacts arranged in a single row for optimal connectivity.
The maximum voltage rating for this pin header is 250V, making it suitable for moderate power signal transmission.
This model supports a current rating of up to 7A, allowing for efficient electrical performance in various applications.
The housing is made of polyester, while the contacts are constructed from brass and plated with tin for reliable conductivity.
It operates safely within a temperature range of -40°C to 105°C, suitable for varied environmental conditions.
This pin header is designed for through-hole mounting, providing a secure attachment to the PCB.
The tail pin length is 4.37 mm, ensuring stable and accurate insertion into PCB sockets.
The mating pin length is 11.43 mm, allowing for effective connection during assembly.
This model features an unshrouded design, which facilitates easy access and insertion during assembly and maintenance.
It supports board-to-board and wire-to-board connector systems, making it versatile for various applications.
The Molex KK 396 Series pin header is manufactured in India.
