Molex KK 254 Series Right Angle Through Hole Pin Header 5 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-05-7058
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.8mm |
| Mating Pin Length | 6.71 |
Key Features
- Features a single row unshrouded design for flexible PCB connection.
- Constructed with a nylon housing offering robustness and abrasion resistance.
- Contacts are made from brass with tin plating for corrosion resistance.
- Supports operating temperatures from -40°C up to 105°C for durable performance.
- Rated for 4A current and 500V voltage, suitable for various electronic applications.
- Right angle orientation facilitates installations near PCB edges and tight spaces.
- Through hole mount type allows secure and easy assembly to printed circuit boards.
- Tail pin length of 3.8 mm and mating pin length of 6.71 mm ensure reliable electrical connections.
Product Description
Molex 22-05-7058 KK 254 Series Right Angle Through Hole Pin Header is a precision component engineered for reliable electrical connections in electronic device design and manufacturing.
This pin header features a single row with 5 male contacts spaced at a 2.54 mm pitch, making it compatible with a wide range of printed circuit board configurations. The right angle orientation is ideal for installations where PCB mounting space is constrained or located near board edges.
The housing is made from durable nylon material that withstands abrasion and impact in demanding industrial and manufacturing environments. The brass contacts with tin plating provide corrosion resistance ensuring long-term connector reliability even in humid conditions.
Rated for a current capacity of 4 amperes and voltage up to 500 volts, this pin header is suitable for signal transmission in various electronic components and power connectors. Its through hole mounting style uses solder termination, enabling strong and stable connections, particularly useful in applications involving vibration or mechanical stress.
Molex KK 254 Series pin headers support wide operating temperature ranges from -40°C to 105°C, making them suitable for industrial, laboratory, and commercial electronics assemblies.
Features a single row unshrouded design enabling flexible wiring layouts. Robust nylon housing provides chemical and mechanical resistance. Brass contacts with tin plating ensure excellent conductivity and durability. Right angle configuration simplifies PCB space management.
Designed for wire-to-board connections with friction lock capability. Can be remated multiple times (up to 25) without degradation. Applications include signalling systems, manufacturing equipment, and electronic device design.
Supports through hole mounting for secure electrical and mechanical bonding. This product contains 5 contacts arranged in a single row with 2.54 mm pitch, making it compatible with the KK 254 series PCB headers. For more options in electronic components, explore the PCB Headers category at EnvMart.
Explore more products in our PCB Pin Header category.
