Cosel MGFW DC/DC Converter, 15W, 5V/-5V Output, 1.5A, 18 - 48V DC Input, PCB Mount, MGFW154805-R
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGFW DC/DC Converter, 5V dc, -5 V dc/ 1 |
| Brand | Cosel |
| Efficiency | 84% |
| Length | 25.4mm |
| Model | MGFW154805-R |
| Depth | 9.9mm |
| Gross Weight | 20g |
| Width | 9.9mm |
| Mount Type | PCB |
| Series | MGFW |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 48V dc |
| Standards/Approvals | CE, cUL, UL 60950-1, cULus, EN 60950-1, TUV |
| Minimum Input Voltage | 18V |
| Number of Pins | 6 |
| Output Voltage 1 | 5, -5V dc |
| Output Current 1 | 1.5A |
| Output Voltage Adjustment Range | 5.24 V |
| Isolation Voltage | 500V dc |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
| High efficiency | synchronised rectification circuit (MGS10 / MGS15 / MGFS15 / MGS30 / MGFS30) |
Key Features
- Capable of providing dual outputs of 5V and -5V DC at 1.5A each.
- Wide input voltage range from 18V to 48V DC for versatile integration.
- Compact PCB mount design ideal for space-constrained layouts.
- Delivers a maximum output power of 15W suitable for demanding loads.
- High efficiency up to 84% ensuring reduced energy losses.
- Isolation voltage of 500V DC enhances operational safety.
- Operating temperature range from -40°C to 85°C supports extreme environments.
- Low ripple and noise rated at 150mV peak-to-peak for stable output.
Product Description
Cosel MGFW154805-R DC/DC Converter delivers reliable dual-output capability with 5V and -5V DC at 1.5A, engineered for demanding industrial and electronics environments requiring efficient power conversion. Its wide input voltage span from 18V to 48V DC allows seamless integration into varied power architectures, making it a practical solution for diverse electronic designs.
The converter features a compact PCB mount form factor with a DIP package, enabling space-saving installations. The maximum output power is rated at 15W, which addresses both low and medium power needs in automation, industrial controls, and communication systems.
Capable of supplying dual outputs of 5V and -5V DC, each supporting up to 1.5A. Wide input voltage range from 18V to 48V DC supports adaptation in flexible and mobile applications. PCB mountable for straightforward inclusion in custom circuit designs and test benches.
High energy efficiency of 84% to optimize system-level power consumption. Low output ripple and noise (150mV peak-to-peak) for sensitive equipment and instrumentation. Robust isolation voltage of 500V DC for reinforced circuit safety.
Stable operation in environments from -40°C up to 85°C, suitable for harsh industrial settings. Built-in protection circuits increase reliability and safeguard the device in abnormal conditions. No built-in aluminium or tantalum electrolytic capacitors, contributing to long-term reliability.
The MGFW Series DC-DC converters are recognized for high reliability, synchronous rectification, and onboard protection features. Typical applications include industrial instrumentation, control panels, telecommunications hardware, and laboratory electronics.
The module’s small size (25.4mm × 9.9mm × 9.9mm) and lightweight (20g) nature facilitate easy handling and design integration. Designed with industrial standard SIP6 configuration, the converter is well-suited for PCB power supply upgrades and compact system builds.
Explore the complete Cosel MGFW series and other DC-DC Converters on EnvMart for dependable power conversion solutions in all industrial and laboratory environments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 15W, suitable for demanding loads.
It accepts a wide input voltage range from 18V to 48V DC, allowing for versatile integration into various applications.
This unit provides dual outputs of 5V and -5V DC, each capable of delivering up to 1.5A.
The efficiency of the Cosel MGFW DC/DC Converter is rated at 84%, which helps reduce energy losses.
It features an isolation voltage of 500V DC, enhancing operational safety in various applications.
The dimensions of this model are 25.4mm in length, 9.9mm in width, and 9.9mm in depth.
It operates within a temperature range of -40°C to 85°C, making it suitable for extreme environments.
The output ripple and noise are rated at 150mV peak-to-peak, which is suitable for sensitive applications.
This model is designed for PCB mounting, facilitating easy integration into custom circuit designs.
It complies with several standards including CE, cUL, UL 60950-1, and TUV, ensuring safety and reliability.
No, this model does not include built-in aluminium or tantalum electrolytic capacitors, contributing to its reliability.
This converter is suitable for applications in industrial instrumentation, control panels, telecommunications hardware, and laboratory electronics.
