ABB Tmax XT Molded Case Circuit Breaker, 4-Pole, 25A, Breaking Capacity 150 kA, Fixed, 690V 1SDA067661R1 XT2L 160 TMD 25A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA067661R1 XT2L 160 TMD 25A FF |
| Depth | 82.5mm |
| Width | 120mm |
| Mount Type | Fixed |
| Current Rating | 25A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 150kA |
| Number of Poles | 4 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 25 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Provides high breaking capacity of 150 kA for enhanced safety.
- Features fixed mount design for secure installation.
- Operates at rated AC voltage up to 690V and DC voltage up to 500V.
- Thermal magnetic tripping mechanism ensures reliable circuit protection.
- Front terminals and lever reset actuator enable user-friendly operation.
- Supports frequency range of 50/60 Hz for versatile application.
- Certified for CE, IEC, and RoHS standards compliance.
- Ideal for industrial, commercial, and electrical distribution applications.
Product Description
ABB 1SDA067661R1 XT2L 160 TMD 25A FF Molded Case Circuit Breaker is engineered for advanced protection of electrical distribution networks, featuring four poles and a current rating of 25A. This MCCB is equipped with a robust breaking capacity of 150 kA, ensuring safe interruption in the event of overcurrent or short-circuit conditions.
High breaking capacity of 150 kA ensures safety in demanding environments. Fixed mount design simplifies secure installation in panel systems. Supports rated AC voltage up to 690V and DC voltage up to 500V, fitting diverse electrical requirements.
Thermal magnetic tripping mechanism offers reliable overload and short-circuit protection. Front terminal access and lever reset actuator support convenient maintenance and operation. Operates at 50/60 Hz, suitable for global industrial and commercial standards.
Compliant with CE, IEC, and RoHS certifications. Designed for efficient disassembly and sustainability, recognized as a Better World Product. Compact form factor: 130mm (height) x 120mm (width) x 82.5mm (depth).
This circuit breaker is ideal for automation, industrial manufacturing, and commercial electrical distribution networks. Its robust specifications are suited for demanding environments, ensuring safety, reliability, and compliance with international standards. The device features advanced thermal magnetic trip technology and provides easy access for maintenance. Applications include industrial panels, switchgear assemblies, and commercial distribution boards.
Explore more ABB MCCBs and Circuit Breakers in the Electronics & Electricals category on EnvMart to enhance your system safety and versatility.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this circuit breaker is 150 kA, ensuring safe interruption during overcurrent or short-circuit conditions.
This model has a rated current of 25A, suitable for various electrical distribution applications.
It supports a rated AC voltage of up to 690V and a rated DC voltage of up to 500V.
This unit features four poles, making it suitable for multi-phase applications.
It employs a thermal magnetic tripping mechanism for reliable overload and short-circuit protection.
The dimensions are 130mm in height, 120mm in width, and 82.5mm in depth.
This model features a fixed mount design, simplifying secure installation in panel systems.
It operates at a frequency range of 50/60 Hz, making it versatile for global applications.
It is certified for CE, IEC, and RoHS compliance, ensuring adherence to international standards.
This circuit breaker uses a lever reset actuator for convenient maintenance and operation.
The country of origin for this circuit breaker is Italy.
It is ideal for industrial, commercial, and electrical distribution applications, including automation and manufacturing.
