Wurth Elektronik 3460B Series Pluggable Terminal Block, 5-Contact, 2.5 mm Pitch, 1 Row, 691346000005B
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 150V |
| Brand | Wurth Elektronik |
| Colour | Black |
| Orientation | Vertical |
| Current | 6A |
| Length | 13.6mm |
| Model | 691346000005B |
| Depth | 15mm |
| Width | 5mm |
| Housing Material | Polyamide |
| Series | 3460B |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Number of Contacts | 5 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 0.5mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 20AWG |
| Wire Connection Method | Push-in |
| Insulator Flammability Rating | UL94 V-0 |
Key Features
- Pluggable terminal block with 5 contacts for versatile PCB applications.
- 2.5 mm pitch ensures compact spacing and reliable electrical connections.
- Single row configuration enhances organized wiring.
- Supports cable sizes from 0.2 mm² to 0.5 mm², both solid and stranded wires.
- Push-in wire connection method provides efficient installation.
- Male connector gender with vertical orientation for straightforward placement.
- Rated for 6A current and 150V voltage, suitable for various electronics projects.
- Housing made from durable polyamide with UL94 V-0 flammability rating.
Product Description
Wurth Elektronik introduces the 3460B Series Pluggable Terminal Block, model 691346000005B, designed to deliver high reliability for PCB connectivity in industrial and electronic applications. This terminal block features 5 contacts, a 2.5 mm pitch, and a single row layout that ensures efficient space utilization and organized wiring.
Manufactured from polyamide housing with UL94 V-0 flammability rating, the terminal block offers robust fire resistance and durability, making it suitable for demanding environments. The terminal supports both solid and stranded cable sizes from 0.2 mm² to 0.5 mm², accommodating a wide range of wiring needs. Its push-in wire connection method simplifies installation and maintenance while ensuring strong and secure electrical contact.
Rated for a current of up to 6A and voltage up to 150V, this terminal block meets the requirements of various industrial, laboratory, and commercial electronic systems. The male connector gender and vertical orientation facilitate straightforward component placement on PCBs.
Pluggable terminal block with 5 contacts for diverse electronics projects. Compact 2.5 mm pitch allowing for dense PCB layout. Effective for cable sizes between 0.2 mm² and 0.5 mm², both solid and stranded. Easy push-in connection system enabling quick and reliable installation.
Single row structure for organized wire management. Polyamide housing delivers durability and meets stringent UL94 V-0 standard. Operating temperature ranges from -40°C to +105°C for wide industrial usage. Contact resistance as low as 20 mΩ for minimal energy loss.
The compact dimensions (Length: 13.6 mm, Width: 5 mm, Depth: 15 mm) make it an ideal choice for electronics, power supplies, control panels, and automation circuits. Typical applications include industrial battery chargers, control boards, HVAC systems, laboratory instrumentation, and manufacturing environments requiring reliable terminal blocks.
Black color aids identification and aesthetics. The product is suitable for assembly lines, prototyping, repair, and upgrade projects. Designed for longevity and performance under continuous operation, it maintains reliable performance even at extreme temperatures.
Discover more Pluggable Terminal Blocks in the Electronics & Electricals > Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this terminal block is 2.5 mm, allowing for compact spacing on PCBs.
It is rated for a maximum current of 6A, making it suitable for various electronic applications.
This model can handle voltages up to 150V, suitable for a range of electronic systems.
It supports wire sizes from 0.2 mm² to 0.5 mm², accommodating both solid and stranded wires.
The housing is made from polyamide, which provides durability and a UL94 V-0 flammability rating.
The dimensions are 13.6 mm in length, 5 mm in width, and 15 mm in depth.
It uses a push-in wire connection method, which simplifies installation and ensures secure electrical contact.
The connector is male and has a vertical orientation, facilitating straightforward placement on PCBs.
The minimum wire size is 26 AWG and the maximum is 20 AWG, compatible with various wiring needs.
It operates effectively within a temperature range of -40°C to +105°C, suitable for industrial environments.
Typical applications include industrial battery chargers, control boards, HVAC systems, and laboratory instrumentation.
The country of origin for this terminal block is Taiwan.
