Amphenol Industrial Circular Connector 5 Contacts Panel Mount Plug Female IP68 X-LOK Series BD-05PMFS-QC8001
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500V |
| Brand | Amphenol Industrial |
| Orientation | Straight |
| Current | 5A |
| Model | BD-05PMFS-QC8001 |
| IP Rating | IP68 |
| Mount Type | Panel Mount |
| Housing Material | Nylon |
| Contact Material | Copper |
| Series | X-LOK |
| Termination Type | Plug-In |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 5 |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Shell Size | 20.6 mm |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Plug/Socket | Plug |
Key Features
- Equipped with 5 durable contacts for reliable connectivity.
- Features a secure panel mount design for stable installation.
- Offers female contact gender and plug configuration for versatile usage.
- Provides high ingress protection rated at IP68 for tough environments.
- X-LOK Series ensures quick, bayonet mating and ease of operation.
- Gold plated copper contacts enhance signal integrity and corrosion resistance.
- Withstands operating temperatures from -40°C to 105°C for flexibility.
- Supports up to 5A current and 500V voltage for a range of applications.
Product Description
The Amphenol Industrial BD-05PMFS-QC8001 is a precision-engineered circular connector from the acclaimed X-LOK Series, designed to deliver robust and consistent electrical performance in industrial, automation, and demanding commercial environments. It features 5 gold-plated copper contacts ensuring stable, high-quality connectivity with reduced risk of signal loss. The panel mount plug provides straightforward and secure assembly onto panels or equipment, allowing for fast and reliable hookup.
This connector employs a female contact configuration with plug form-factor and offers a bayonet mating mechanism, enabling quick, tool-less coupling and decoupling. The device supports a current rating up to 5A and voltage up to 500V, making it suitable for a variety of control, signal, and power transmission applications.
Five contacts accommodate multi-line signal or power distribution within equipment and control systems. IP68 ingress protection safeguards the connection against dust, dirt, and prolonged immersion in water, guaranteeing operation in outdoor, wet, or adverse environments.
The nylon body offers superior resistance to mechanical stresses, chemicals, and unpredictable conditions typical in industrial and laboratory settings. Gold-plated copper contacts minimize electrical resistance and enhance long-term reliability by resisting corrosion.
Suitable for use within temperature ranges of -40°C to 105°C, supporting year-round operation in diverse geographies. Panel mount style ensures low-profile, vibration-resistant installation directly onto enclosures, junction boxes, or machinery.
Typical use cases include factory automation, robotics, power control panels, machinery wiring, instrumentation, and equipment interconnects in both commercial and heavy industrial settings. The X-LOK Series' quick-connect bayonet interface streamlines replacement and maintenance procedures, further reducing downtime in mission-critical systems.
For industrial buyers seeking a waterproof, rugged connector solution with multi-contact versatility and proven Amphenol reliability, the BD-05PMFS-QC8001 stands as an optimal choice. Explore the full range of Amphenol Industrial connectors on EnvMart to match your specific requirements.
Explore more products in our Industrial Circular Connector category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of up to 5A and a voltage rating of 500V, making it suitable for various control, signal, and power transmission applications.
This model has an IP68 ingress protection rating, ensuring it is safeguarded against dust and prolonged immersion in water.
The housing is made of nylon, and the contacts are gold-plated copper, which enhances signal integrity and corrosion resistance.
It operates effectively within a temperature range of -40°C to 105°C, allowing for use in diverse environments.
The BD-05PMFS-QC8001 features 5 contacts, accommodating multi-line signal or power distribution.
This model is designed for panel mount installation, providing a secure and low-profile assembly onto panels or equipment.
It employs a bayonet mating mechanism, allowing for quick, tool-less coupling and decoupling.
The shell size of this connector is 20.6 mm, which is standard for its type.
It is suitable for factory automation, robotics, power control panels, machinery wiring, instrumentation, and equipment interconnects.
This model features a female contact configuration, which is typical for plug connectors.
The BD-05PMFS-QC8001 is part of the X-LOK Series, known for its quick-connect features.
The connector is manufactured in China, as indicated by its country of origin.
