JST VH Female Connector Housing 3.96mm Pitch 8 Way Straight Cable Mount Polyamide VHRR-8N

Free Delivery in India | Lowest Global Shipping Charges

JST VH Female Connector Housing 3.96mm Pitch 8 Way Straight Cable Mount Polyamide VHRR-8N



Category PCB Connector Housing Brand JST Condition New

Specifications

Country of Origin	Japan
Brand	JST
Orientation	Straight
Length	31.62mm
Model	VHRR-8N
Width	10.5mm
Mount Type	Cable
Housing Material	Polyamide
Series	VH
Number of Rows	1
Mounting height	16.5 mm
Pitch	3.96mm
For Use With	VH Disconnectable Crimp Style Connectors
Number of Contacts	8
Connector Gender	Female
Contact Design	Box contact

Key Features

Features a compact polyamide housing with 8 contacts arranged in a single row.
Supports a large current carrying capacity of up to 10A for varied signal and power supply circuits.
Includes a locking mechanism for secure installation and resistance to vibration and misinsertion.
Mounts via cable and is suitable for use with VH disconnectable crimp style connectors.
Reliable box contact design ensures stable connection in electronic and industrial applications.
Straight orientation enhances ease of integration on PCB and wiring platforms.
Housing material is robust polyamide providing durability and good electrical insulation.

Product Description

The JST VHRR-8N VH Female Connector Housing is engineered for demanding electronic and industrial applications requiring secure, high-current cable connections. This model features an 8-contact configuration in a single row with a 3.96mm pitch, designed for compatibility with VH disconnectable crimp style connectors.

Its compact polyamide housing accommodates a large current capacity of up to 10A while remaining space-efficient with a mounting height of just 16.5mm. The integrated locking mechanism ensures that connections remain stable under vibration and prevents misalignment or reverse insertion. The box contact design - proven in other JST connector series - delivers reliable electrical performance across signal and power supply circuits.

Mounting is via cable, making this product suitable for quick integration into custom wire harnesses, PCB assemblies, and electronic modules. With a length of 31.62mm and width of 10.5mm, the straight orientation allows for straightforward placement on boards or in control panels. Polyamide material delivers strong mechanical properties and high electrical insulation, supporting both safety and longevity.

VH connector housings are commonly deployed in consumer electronics, industrial equipment, laboratory instrumentation, and commercial devices requiring robust and field-proven performance. Typical applications include signal routing, power distribution, and modular electronic systems.

The product enables precise and secure connections critical for manufacturing, automation, test and measurement, HVAC controls, and water treatment equipment. The locking feature ensures operational stability even in environments subject to mechanical stress or frequent reconfiguration.

Compact 8-way female connector housing with reliable contact design. 10A current capacity makes this suitable for power and signal circuits. Cable mount installation is ideal for custom wire harnesses and PCBs. Durable polyamide construction provides high electrical insulation.

Integrated lock mechanism prevents vibration-induced looseness and misinsertion. 31.62mm × 10.5mm dimensions fit space-constrained panels and circuit boards. Supports industrial, laboratory, and commercial electronics integration.

Straight orientation for streamlined wiring layouts and assembly.
