KEMET R75L Film Capacitor ±10% 330 nF 560 V DC 250 V AC Through Hole R75LN33304000K
Specifications
| Country of Origin | North Macedonia |
|---|---|
| Capacitance Range | 220 pF - 33 μF |
| Brand | KEMET |
| Height | 16mm |
| Length | 26.5mm |
| Model | R75LN33304000K |
| Packaging | Bag |
| Width | 7mm |
| Mount Type | Through Hole |
| Series | R75L |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±10 % |
| Capacitance | 330nF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Radial |
| Dissipation Factor | 0.08% |
| Lead Length | 30mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Pin Count | 2 |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 560V dc |
| Lead Pitch | 22.5mm |
| Lead Diameter | 0.8mm |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 7.5 - 37.5 mm |
Key Features
- Metallized polypropylene film construction ensures durability and reliability.
- Capacitance of 330 nF and tolerance of ±10% for precise performance.
- Rated DC voltage of 560 V and AC voltage of 250 V for versatile applications.
- Through hole mounting with 22.5 mm lead pitch eases PCB integration.
- Operating temperature range from −55°C to +105°C suitable for demanding environments.
- Radial leads electrically welded to metallized film, enhancing self-healing property.
- Compliant with RoHS and IEC 60286-2 standards for quality assurance.
- Plastic case with thermosetting resin is solvent-resistant and self-extinguishing.
Product Description
The KEMET R75L Film Capacitor, model R75LN33304000K, is engineered for reliable energy storage and filtering in electronic circuits. With a capacitance of 330 nF and a tolerance of ±10%, this capacitor delivers high precision and stable performance across a broad voltage range. Rated for 560 V DC and 250 V AC, it is suitable for demanding applications such as power electronics, industrial controls, and high-frequency circuits.
Designed as a through hole component with a 22.5 mm lead pitch, it simplifies mounting and ensures robust mechanical stability. The capacitor’s radial leads, constructed from tinned wire, are electrically welded to the metallized polypropylene film, facilitating self-healing and longevity. The plastic case is solvent-resistant and self-extinguishing, filled with thermosetting resin material, providing enhanced safety and resistance to environmental factors.
Operational across a wide temperature range from −55°C to +105°C, the R75LN33304000K is suitable for various industrial and electronics environments. Its compact dimensions - 26.5 mm length, 7 mm width, and 16 mm height - make it an ideal choice for space-constrained designs. The capacitor features a lead diameter of 0.8 mm and a lead length of 30 mm, supporting ease of integration into PCBs.
Meeting RoHS and IEC 60286-2 standards, the KEMET R75L series exemplifies quality and compliance, ensuring reliable performance in industrial, automotive, and high-frequency segments. The device offers a dissipation factor of 0.08%, guaranteeing efficient energy transfer and minimal loss. The capacitor is supplied in bags for easy handling and bulk assembly operations.
Applications for this capacitor range from industrial automation and power supplies to electronic filtering and transient voltage suppression. Its construction and specification make it well-suited for professional electronics manufacturing and laboratory testing environments.
Explore more high-quality KEMET capacitors and related passive components in the Film Capacitors category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 330 nF with a tolerance of ±10%.
It is rated for a DC voltage of 560 V and an AC voltage of 250 V.
The operating temperature range is from −55°C to +105°C, making it suitable for demanding environments.
This model has a length of 26.5 mm, a width of 7 mm, and a height of 16 mm.
It features through hole mounting with a lead pitch of 22.5 mm, facilitating easy PCB integration.
The lead length is 30 mm and the lead diameter is 0.8 mm.
The capacitor is constructed with metallized polypropylene film and has a plastic case made of thermosetting resin, which is solvent-resistant and self-extinguishing.
This capacitor is compliant with RoHS and IEC 60286-2 standards, ensuring quality assurance.
The dissipation factor for this model is 0.08%, which indicates efficient energy transfer.
It is suitable for applications such as power electronics, industrial controls, and high-frequency circuits.
The capacitor features radial leads that are electrically welded to the metallized film, enhancing its self-healing properties.
The KEMET R75L Film Capacitor is supplied in bags for easy handling and bulk assembly operations.
