WIMA Film Capacitor 1.5 nF 100 V DC 63 V AC ±5% Through Hole FKP2

The WIMA FKP2/1500/100/5 Film Capacitor is engineered for high precision and reliability in demanding electronic applications. Featuring a capacitance of 1.5 nF with a tight ±5 % tolerance, this capacitor is ideal for circuits requiring accurate signal retention and filtering.

Designed with a through-hole mount configuration, the capacitor provides secure installation and dependable performance in both professional and industrial PCB layouts. Its 100 V DC and 63 V AC voltage ratings allow it to operate safely under typical circuit conditions, minimizing the risks of failure or signal loss.

The FKP2/1500/100/5 utilizes a durable plastic case, offering robust insulation and mechanical protection against environmental influences. Lead pitch is 5 mm with a lead length of 8.5 mm, supporting straightforward solder mounting and thermal stability. Two solder terminals guarantee direct connection to PCB traces for low-loss operation.

This capacitor is compliant with RoHS, ISO 9001:2008, and DIN EN ISO 14001:2004 standards, ensuring quality, reliability, and sustainability. Its insulation resistance exceeds 5x105 MΩ, while a temperature coefficient of -200 ppm/°C helps maintain electrical stability across operating ranges.

Typical applications include sampling circuits, oscillator circuits, LC filtering, timing elements, and audio equipment where consistent electrical properties are paramount. The capacitor withstands temperatures from -55°C to 100°C and features a maximum pulse rate-of-change of 1000 V/μs, suitable for high-frequency signal handling.

Height, length, and width are 6 mm, 7.2 mm, and 4.5 mm respectively, ensuring compact integration into densely packed electronics assemblies.

This product is part of the WIMA FKP2 series, renowned for their quality and dependable performance. Explore more film Capacitors and passive components on EnvMart for industrial, laboratory, and commercial use.
