Process Digital pH Probe HI1006-4810, HF Acid Resistant, PVDF/PTFE, 10m, RS485 | EnvMart

Free Delivery in India | Lowest Global Shipping Charges

Hanna HI1000 Series Process Digital pH Probe-10m (32.8')-HF - Hydrofluoric Acid Resistant-PTFE

Name: Hanna HI1000 Series Process Digital pH Probe-10m (32.8')-HF - Hydrofluoric Acid Resistant-PTFE
Brand: Hanna
SKU: 72307
Price: 539.96 USD
Availability: InStock



Category pH Electrodes Brand Hanna

Specifications

Measurement Range	LT: 0–12 pH; HT: 0–14 pH; HF: 0–10 pH
Body Material	PVDF
Outer Diameter	22.5 mm
Model	HI1006-4810
Cable Length	10 m
Temperature Sensor	Pt100
Max. Pressure	6 bar 87 psi
Reference Cell Type	Double Junction
Type of Electrolyte	polymer
Tip / Shape	flat
Matching Pin	yes
Glass Type	LT (Low Temp) / HT (High Temp) / HF (Hydrofluoric Acid)
Series	HI1000
Junction	PTFE
Body Length	140 mm
Mounting Thread	3/4 in. NPT
Probe Overall Length	140 mm
Environment LT Glass	-5 to 80 °C
Environment HT Glass	0 to 100 °C

Key Features

HI1006-4810 Process Digital pH Probe with hydrofluoric acid resistance and 10m cable for industrial monitoring and control.

Chemically resistant PVDF body with double junction reference for harsh environments.
Flat tip, PTFE junction, and HF glass for optimal performance with aggressive media.
Built-in Pt100 temperature sensor for automatic temperature compensation.
Supports digital data transmission via RS485, ensuring immunity to electrical interference.
Compatible with HI510 Universal Process Controller for seamless integration.
Mounts using a 3/4 in. NPT threaded connection for in-line or submersion applications.
Temperature range varies by glass type, accommodating high, low, and hydrofluoric applications.
Glass types available: LT (low temperature), HT (high temperature), and HF (hydrofluoric acid).
Measurement ranges: LT (0-12 pH), HT (0-14 pH), HF (0-10 pH).
Max pressure rating of 6 bar (87 psi) enables robust industrial use.

Product Description

The HI1006-4810 is a high-performance process digital pH probe from the HI1000 Series designed for industrial applications that demand accuracy and durability even under chemical stress. With a chemically resistant PVDF body, flat tip, and advanced PTFE junction, this probe is engineered to monitor and control pH in environments containing hydrofluoric acid and other aggressive chemicals.

It is equipped with a built-in Pt100 temperature sensor for effective temperature compensation, ensuring precise readings across variable process conditions. The probe transmits measurements digitally via an RS485 interface, providing robust immunity against electrical interference encountered with conventional analog probes.

Chemical and mechanical resistance with polymer electrolyte and PVDF housing.
Supports up to 10 meters (32.8 ft) direct wire connection for process installations.
Three select glass types for diverse industrial applications, including HF resistance.
Double junction reference cell minimizes contamination and maintenance.
Flat-tipped sensing surface to reduce fouling and simplify cleaning procedures.
Environmentally flexible: LT glass (−5 to 80°C), HT glass (0–100°C), HF glass suitable for <2g/L, 2°C minimum temperature.
Easy integration via 3/4" NPT threaded mounting for in-line and submersible placements.
Compatible with the HI510 Universal Process Controller, widely used in industrial, laboratory, chemical, and water treatment systems.
Measurement ranges mean it can support food, pharma, chemical, and wastewater processing environments with reliable accuracy.

Ideal for industrial pH measurement in chemical plants, water and wastewater treatment, research laboratories, manufacturing operations, and any process requiring reliable, accurate pH control—especially where hydrofluoric acid or aggressive cleaning is necessary.
