Hanna Chlorine, pH, ORP, and Temperature Analyzers - PCA300 Series-PCA320 - Chlorine, pH & Temperature
Specifications
| Country of Origin | India |
|---|---|
| Package Contents | Analyzer unit (without reagents); all standard fittings |
| Temperature Accuracy | ±0.5 °C (±1.0 °F) |
| Power Supply | 115 VAC ±10% or 230 VAC ±10%, 50/60 Hz, 20 VA |
| Dimensions | 318 x 267 x 159 mm |
| Temperature Resolution | 0.1 °C (0.1 °F) |
| Temperature range | 5.0 to 75.0 °C |
| Sample flow rate | 100 to 300 mL/min |
| pH Range | 0.00 to 14.00 pH |
| pH Resolution | 0.01 |
| pH Accuracy | ±0.05 pH |
| pH Calibration | Automatic one or two points; one point process calibration |
| ORP Range | 0 to 2000 mV (PCA330) |
| ORP Resolution | 1 mV (PCA330) |
| ORP Accuracy | ±1 mV (PCA330) |
| Logging Memory | 3500 log records |
| Model | PCA320 |
| Free Chlorine Range | 0.00 to 5.00 mg/L (ppm) |
| Free Chlorine Resolution | 0.01 mg/L (ppm) |
| Free Chlorine Accuracy | ±8% or ±0.05 mg/L (whichever is greater) |
| Alarm Relay Set Point | SPDT contact with 5A, 230V resistive load |
| Enclosure | NEMA-4X, molded fiberglass polyester with transparent Lexan window |
| Weight | 5 kg |
| Baud rate | 1200 - 2400 - 4800 - 9600 bps |
| SAMPLE TEMPERATURE | 5 to 40 °C (41 to 104 °F) |
| Drain Connection | 10 mm (3/8 in.) barb |
| Product Condition | New |
| MPN | PCA320 |
| Total Chlorine Range | 0.00 to 5.00 mg/L (ppm) |
| Total Chlorine Accuracy | ±8% or ±0.05 mg/L (whichever is greater) |
| Total Chlorine Resolution | 0.01 mg/L (ppm) |
| Analog Output Signal | 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA, 0-20 mA |
| Dosing Control | SPDT contact with 5A, 230V resistive load |
| pH Dosing Set Point | Selectable from 0.10 to 2.00 pH |
| Chlorine Calibration | One point process calibration |
| Chlorine Dosing Set Point | Selectable from 0.1 to 5 mg/L (ppm) |
| pH Hysteresis Band | Selectable from 0.05 to 2.00 pH |
| Sample Inlet/Outlet Connection | 12 mm (1/2") male NPT fitting |
| Inlet Sample Pressure | 0.07 to 4 bar |
| RS485 Connectivity | Yes, galvanically separated |
| Chlorine Sampling Rate | Adjustable from 3 to 90 minutes |
Key Features
PCA320 Chlorine, pH, ORP & Temperature Analyzer for industrial water quality management.
- Continuously monitors chlorine, pH, ORP, and temperature with microprocessor control.
- Chlorine measurement range from 0.00 to 5.00 mg/L (ppm) with high accuracy and resolution.
- NEMA-4X molded fiberglass polyester enclosure offers robust protection for demanding environments.
- Selectable analog output signals, including 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA, and 0-20 mA.
- Character LCD (4x20) for multilingual operation and clear data display.
- Dosing and alarm relay setpoints for automated process control.
- Adjustable chlorine and pH sampling rates for optimal data logging.
- RS485 galvanically separated connectivity for safe, reliable integration.
- Automatic one- or two-point pH calibration and process calibration for all parameters.
- Supports industrial water treatment, municipal, swimming pool, and HVAC monitoring applications.
Product Description
The PCA320 Chlorine, pH, ORP, and Temperature Analyzer is a microprocessor-controlled process analyzer designed for continuous monitoring and control of key water quality parameters. With its advanced functionality, the PCA320 measures free and total chlorine, pH, ORP, and temperature in real time, enabling efficient process management in drinking water, wastewater, pool, and industrial HVAC applications.
This robust analyzer features a molded fiberglass polyester enclosure built to NEMA-4X standards, protecting the electronics in harsh environments. Configurable analog output signals (0-10 mV, 0-100 mV, 0-1 V, 4–20 mA, and 0–20 mA) provide seamless integration with process control systems. User-friendly 4-line by 20-character LCD supports English, Italian, Portuguese, and Spanish for ease of use by operators worldwide.
- Chlorine measurement range of 0.00–5.00 mg/L with accuracy ±8% or ±0.05 mg/L.
- Automatic one- or two-point pH calibration and selectable dosing setpoints for both pH and chlorine control.
- Alarm relay (SPDT contact, 5A/230V) and proportional dosing relay for reliable process automation.
- RS485 connectivity enables integration with industrial control and SCADA systems.
- Extensive logging capacity with up to 3500 log records for compliance and troubleshooting.
- Sample flow rate of 100–300 mL/min and inlet sample pressure of 0.07 to 4 bar (external regulator required above 4 bar).
- Molded enclosure with transparent Lexan window ensures both durability and visibility.
This analyzer is ideal for industrial, municipal, laboratory, pool/spa, and water treatment environments. The package contains the analyzer itself (without reagents), as well as all necessary fittings and accessories for rapid commissioning.
Explore more measuring and water quality instruments in the EnvMart Measuring & Testing Instruments category for holistic water management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PCA320 Analyzer continuously measures chlorine, pH, ORP, and temperature, providing comprehensive monitoring for water quality management.
The chlorine measurement range is from 0.00 to 5.00 mg/L (ppm) with an accuracy of ±8% or ±0.05 mg/L.
Yes, the PCA320 features a NEMA-4X molded fiberglass polyester enclosure, providing robust protection against harsh environmental conditions.
The analyzer offers selectable analog output signals including 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA, and 0-20 mA for easy integration with control systems.
Yes, the user-friendly 4-line by 20-character LCD supports multiple languages including English, Italian, Portuguese, and Spanish.
The PCA320 has an extensive logging capacity with up to 3500 log records, which is useful for compliance and troubleshooting.
The analyzer supports automatic one- or two-point pH calibration and process calibration for all parameters, ensuring accurate readings.
The sample flow rate is between 100 to 300 mL/min, and an external regulator is required for inlet sample pressures above 4 bar.
The PCA320 is ideal for industrial water treatment, municipal applications, swimming pool monitoring, and HVAC systems.
The package includes the PCA320 Analyzer itself (without reagents) and all necessary fittings and accessories for rapid commissioning.
