Hanna Panel-mounted pH Analog Indicator with Self Diagnostic Test – HI8510
Specifications
| Country of Origin | India |
|---|---|
| Display | LCD |
| Power Supply | 115 or 230 Vac; 50/60 Hz |
| Dimensions | 141 x 69 mm |
| pH Range | 0.00 to 14.00 pH |
| pH Resolution | 0.01 pH |
| pH Accuracy | ±0.02 pH (0 to 100 °C) / ±0.05 pH (-20 to 0 °C) (electrode); ±0.5% (transmitter) |
| Environment | -10 to 50°C; max RH 95% non-condensing |
| pH Calibration | 0.01 pH |
| pH Temperature Compensation | 0.00 to 14.00 pH |
| Model | HI8510 |
| Enclosure | Black anodized aluminum body; ABS transparent splash-proof front cover |
| Weight | 1.00 kg |
| Backlight | Continuous ON |
| Voltage Output | ±5 Vcc; 150 mA max load for amplified electrodes |
| Product Condition | New |
| MPN | HI8510 |
| Analog Output Signal | ±0.02 pH (0 to 100 °C) / ±0.05 pH (-20 to 0 °C) (electrode); ±0.5% (transmitter) |
| Electrode Connection | BNC input; amplified probe; transmitter input |
| Front Panel Protection | Transparent splash-proof cover |
Key Features
HI8510 Panel-mounted pH analog indicator with self diagnostic test for precision pH monitoring in process control applications.
- Offers highly accurate pH measurement with ±0.02 pH (0 to 100 °C) and ±0.05 pH (-20 to 0 °C).
- Features continuous ON backlight and large, easy-to-read LCD display for clear visual data.
- Supports BNC input, amplified probe input, and transmitter input for versatile electrode compatibility.
- Automatic temperature compensation ensures reliable and fast readings in varying environments.
- Includes removable, transparent splash-proof cover protecting front panel operations.
- Built-in autodiagnostic functions help check pH electrode and instrument status.
- Quick and easy connection system for rapid installation or electrode swaps.
- Dimensions: 141 x 69 mm (5.6 x 2.7”) and robust enclosure with aluminum body.
- Operates in environments from -10 to 50°C and max 95% RH non-condensing.
- 115 or 230 Vac, 50/60 Hz power supply for industrial and laboratory use.
Product Description
HI8510 is a precision panel-mounted pH analog indicator equipped with self-diagnostic test capabilities, engineered for laboratory and industrial process control systems. Featuring ±0.02 pH accuracy within 0–100 °C and ±0.05 pH accuracy from -20 to 0 °C, it ensures reliable monitoring of pH parameters. The device utilizes a large LCD display with continuous backlight for easy interpretation of measurement data in various lighting environments.
The instrument supports BNC input, amplified probe input, and transmitter input, making it adaptable for different electrode types and field requirements. Automatic temperature compensation and built-in autodiagnostics help maintain consistently accurate readings and monitor the electrode and instrument condition over time. A removable, transparent splash-proof cover ensures front panel safety even in humid or challenging laboratory settings.
- Highly accurate pH analog indicator with ±0.02 pH (0–100 °C) and ±0.05 pH (-20 to 0 °C).
- Continuous ON backlight with large LCD display for clear data readings.
- Multi-type input: BNC, amplified probe, and transmitter-compatible for versatile lab setups.
- Automatic temperature compensation guarantees precise pH values irrespective of ambient variation.
- Self-testing diagnostics and membrane keypads for ease of operation and maintenance.
- Splash-proof design enhances use in demanding laboratory or industrial environments.
- Enclosure constructed with black anodized aluminum and ABS for rugged durability.
- Operates in -10 to 50°C conditions; suitable for RH max 95% non-condensing atmosphere.
- Dual power supply: 115 or 230 Vac, 50/60 Hz for flexible laboratory and field integration.
- Accurate voltage output for amplified electrodes (±5 Vcc, up to 150 mA).
Industrial applications include water treatment plants, chemical laboratories, process industries, and HVAC systems where accurate pH monitoring and easy panel integration are essential. This indicator is ideal for continuous process monitoring, compliance reporting, and laboratory research.
Browse more process indicators, laboratory measuring instruments, and industrial control devices in the EnvMart catalog for tailored solutions to your analytical and automation needs.
