Semi Automatic Plastic Pet Bottle Blow Machine DEG-3L, 2 Cavity, 1000 BPH, 2L Max Volume
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 380 V/3PH/50Hz |
| Material | PET |
| Net Weight | 850 kg |
| Model | DEG-3L |
| Mould Cavity | 2 Cavity |
| Operation | Semi Automatic |
| Total Power | 10 kW |
| Clamping Force | 100 KN |
| Air Compressor | 30–40 Bar |
| Theoretical Output | 1000 BPH |
| Product Condition | New |
| Max Container Volume | 2 L |
| Clamping Stroke | 160 mm |
| Heating Zones | 4 Sections |
| Max Stretching Stroke | 360 mm |
| Max Mold Thickness | 300 mm |
| Max Container Diameter | 360 mm |
| Max Container Height | 380 mm |
Key Features
DEG-3L Semi Automatic PET Bottle Blow Machine for up to 2L bottles, 2-cavity, 1000 BPH capacity.
- DEG-3L model supports 0.1–2L PET bottle production.
- Theoretical output up to 1000 bottles per hour (500 ml size).
- Includes 2-cavity mold for efficient cycle times.
- Advanced PLC with 0.01 sec time precision, single-operator operation.
- Clamping force: 100KN; Max container volume: 2L.
- Heating and air systems tailored for PET preforms.
Product Description
The DEG-3L Semi Automatic PET Bottle Blow Machine is designed for industrial-grade PET bottle production up to 2 litres per container. Featuring a 2-cavity configuration and a powerful 100KN clamping force, it enables high-speed operation with theoretical outputs up to 1000 BPH (for 500 ml bottles). Its advanced PLC control panel and adjustable infrared preform heater ensure accurate and efficient production, while single-operator controls and flexible installation support streamlined workflows. The robust construction allows for long-term, low-maintenance use in beverage, food, and industrial liquid packaging facilities. Multiple air compressors and independent temperature zones optimize forming for a range of bottle formats and volumes.
- PLC system with optimal time precision (0.01 sec) and operator safety.
- Max container volume: 2L; Max container diameter: 360mm; Max height: 380mm.
- Low waste rate (less than 0.1%) and rapid mold change capability.
- Heating and stretching systems suited for complex preform geometry.
- Total loaded power: 10kW; 380V/3-Phase/50Hz.
- Ideal for mineral water, edible oil, soft drinks, and detergent packaging production.
DEG-3L PET bottle machines help automate small and medium batch bottling tasks. For more semi-automatic bottle blowing solutions, see PET Bottle Blowing Machines at EnvMart.
Frequently Asked Questions
The DEG-3L Semi Automatic PET Bottle Blow Machine can produce bottles with a maximum volume of 2 liters.
This machine has a theoretical output of up to 1000 bottles per hour, specifically for 500 ml bottles.
The DEG-3L is designed to work with PET preforms, accommodating various geometries for efficient bottle production.
Yes, the DEG-3L features a single-operator control system and an advanced PLC for precise operation, making it user-friendly.
The machine has a clamping force of 100KN, ensuring stable and efficient bottle forming.
The DEG-3L requires a total loaded power of 10kW and operates on a 380V/3-Phase/50Hz electrical supply.
This machine is ideal for packaging mineral water, edible oils, soft drinks, and detergents.
The DEG-3L boasts a low waste rate of less than 0.1%, thanks to its efficient design and technology.
Yes, the DEG-3L features rapid mold change capabilities, allowing for quick adjustments between different bottle formats.
For more information or to inquire about purchasing the DEG-3L, please visit our website or contact our sales team directly.
