Kusam Meco Bench Top Digital Multimeter KM3560

SKU ADPBJ Category Multimeters Brand KUSAM-MECO Condition New

Specifications

Country of Origin India
Package Contents Kusam Meco KM 3560 Bench Top Digital Multimeter / Power Cord
DC Voltage Range 100mV/1V/10V/100V/1000V
AC Voltage Range 100mV/1V/10V/100V/750V
Capacitance Range 1nF/10nF/100nF/1µF/10µF/100µF
Temperature Accuracy ±0.2°C Without Accuracy Of Probe
Resistance Range 100Ω/1kΩ/10kΩ/100kΩ/1MΩ/10MΩ/100MΩ
Frequency range 5Hz~1MHz
Brand Kusam Meco
Power Supply 115V/230V 50Hz 15VA
Dimension Approx 256L X 106W X 322H mm
Interface USB Host/USB Device/RS-232/LAN/GBIP Optional
Temperature range -200°C~800°C
Model KM3560
Weight Approx 3.5kg
Safety IEC61010-1 2001 CAT I 1000V/CAT II 600V Class Of Pollution 2
DC Voltage Accuracy ±(0.012+0.005)
Frequency Accuracy ±0.02
Resistance Accuracy ±(0.03+0.005)
DC Current range 100µA/1mA/10mA/100mA/1A/10A
AC Current range 100µA/1mA/10mA/100mA/1A/10A
DC Current Accuracy ±(0.05+0.007)
AC Voltage Accuracy ±(0.2+0.1)
Capacitance Accuracy ±(0.2+0.5)
AC Current Accuracy ±(0.5+0.1)

Key Features

  • High-speed 500 readings/s with true 5½-digit (119999 count) resolution
  • Auto range, diode, and continuity testing functions
  • Math functions include MAX/MIN, Rel, dB, dBm, and statistics
  • 4.3-inch color touch LCD with dual front/rear inputs
  • Displays data trends, histograms, and bar charts

Product Description

Kusam Meco KM3560 Bench Top Digital Multimeter is built for laboratory and industrial precision. It features a 120000 count color LCD for True RMS AC and DC measurements of voltage, current, and resistance. With a reading speed of 500 per second, it delivers fast and accurate data. The rugged design ensures longevity and its intuitive interface makes operation simple. It is the ideal bench tool for engineers needing high performance and stability.

Available on EnvMart, these Bench Multimeters are perfect for high-precision voltage, current, and resistance measurement. Kusam Meco Bench Instruments ensure stability and professional lab-grade accuracy.

Kusam Meco Bench Top Digital Multimeter KM3560
Looking to purchase in bulk?
  • Purchase item in bulk quantity
  • Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum DC voltage range of the Kusam Meco KM3560 multimeter is 1000V.

The Kusam Meco KM3560 can measure AC voltage in the range of 100mV to 750V.

The frequency range supported by the Kusam Meco KM3560 is from 5Hz to 1MHz.

The accuracy of DC voltage measurements on the Kusam Meco KM3560 is ±(0.012+0.005).

The Kusam Meco KM3560 supports USB Host, USB Device, RS-232, LAN, and optional GBIP interfaces.

The weight of the Kusam Meco KM3560 multimeter is approximately 3.5 kg.

The resistance measurement range of the Kusam Meco KM3560 is from 100Ω to 100MΩ.

The Kusam Meco KM3560 can measure temperatures in the range of -200°C to 800°C.

The package contents of the Kusam Meco KM3560 include the multimeter itself and a power cord.

The accuracy of AC current measurements on the Kusam Meco KM3560 is ±(0.5+0.1).

The capacitance measurement range of the Kusam Meco KM3560 is from 1nF to 100µF.

The Kusam Meco KM3560 complies with IEC61010-1 2001 CAT I 1000V/CAT II 600V Class of Pollution 2 safety standards.
