Labtron LVM-D30 Rotational Viscometer
Specifications
| Country of Origin | UK |
|---|---|
| Measurement Range | 25 mPa.s to 10000000 mPa.s |
| Display | LCD |
| Relative Humidity | ≤ 80% |
| Brand | Labtron |
| Power Supply | AC 220 V ±10% / 50 Hz |
| Interface | RS232 |
| Measurement error | ±1% (F.S) |
| Model | LVM-D30 |
| Ambient Temperature (ºC) | 5 to 35°C |
| Temperature Control Range | 45 to 200°C |
| Type of Product | Viscometer |
| Rotation Speed | 0.1 / 0.2 / 0.5 / 1 / 2 / 5 / 10 / 20 / 50 / 100 and 200 rpm |
| Measurement Mode | Automatic |
| Temperature Control Accuracy | ±0.1°C |
| Print output | Needle printer |
| Rotors | Rotor no. 21 / 27 / 28 / 29 (total 4 pieces of spindles) |
| Sample cylinder | 20 ml |
| Wooden Box 01 Dimension (L×W×H) | 595 × 415 × 544 mm |
| Wooden Box 01 Gross Weight | 16.5 kg |
| Wooden Box 02 Dimension (L×W×H) | 425 × 370 × 295 mm |
| Wooden Box 02 Gross Weight | 8.8 kg |
Key Features
- Brookfield rotational viscometer with advanced mechanical design technologies and manufacturing techniques
- 20 ml sample cylinder with temperature control range of 45 to 200°C
- Rotation speed of 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 100 and 200 rpm
- Measurement range of 25 mPa·s to 1×10 mPa·s 7
- Microcomputer technology for temperature control, data collection and data process
- LCD display, real-time display of test data
- Micro-printer with needle printing output
- RS232 communication interface
- High-efficient, stable and reliable
Product Description
Rotational Viscometer LVM-D30 is a Brookfield rotational viscometer, adopted with advanced mechanical design technologies and manufacturing techniques. Features a 20 ml sample cylinder with a temperature control range of 45 to 200°C and rotation speed options of 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 100, and 200 rpm. With a measurement range of 25 mPa·s to 1×10⁷ mPa·s, this viscometer uses microcomputer technologies for temperature control, data collection, and processing. Designed with LCD display, microprinter, and RS232 interface, it is suitable for determining absolute viscosity of Newtonian liquids and apparent viscosity of non-Newtonian liquids.
Applications:
Rotational viscometer is used to measure the viscosity and flow properties of oil, asphalt, plastics, wax, paints, coatings, adhesives, cosmetics, shampoo, toothpaste, and to monitor batch consistency and quality control across chemical, material science, food and beverage industries.
Standard Accessories:
- Viscometer head × 1 set
- Instrument pedestal (with 3 adjustment bolts) × 1 set
- Toothed rod × 1 pc
- Auxiliary controlling case (with temperature controller and microprinter) × 1 set
- Heater × 1 pc
- Spindle (No. 21, 27, 28, and 29) × 1 pc each
- Connection hook and transition bolt × 1 pc each
- Serial port wire × 1 pc
- Heater connection wire × 1 pc
- Sensor wire × 1 pc
- Sample cylinder (with sample cylinder holder, cover, and special forceps) × 1 pc each
- Fuse (Φ5×20) 5 A × 3 pcs
- PC communication CD × 1 pc
Optional Accessories:
- Rotor No. 30
