Hioki Digital Multimeter DT4255
Specifications
| Country of Origin | Japan |
|---|---|
| DC Voltage range | 600.0 mV to 1000 V / 5 ranges / ±0.3 % rdg. ±3 dgt. |
| AC Voltage Range | 6.000 V to 1000 V / 4 ranges / 40 Hz - 1 kHz / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Capacitance Range | 1.000 μF to 10.00 mF / 5 ranges / ±1.9 % rdg. ±5 dgt. |
| Resistance Range | 600.0 Ω to 60.00 MΩ / 6 ranges / ±0.7 % rdg. ±3 dgt. |
| Display | 4-digit LCD / max. 6000 digits / bar graph |
| Frequency range | 99.99 Hz to 99.99 kHz / 4 ranges / ±0.1 % rdg. ±1 dgt. |
| Diode Test | ≤5.0 V open terminal voltage / ≤0.5 mA test current |
| Brand | HIOKI |
| Power Supply | 4× LR03 alkaline batteries / 130 hours (backlight OFF) |
| Dimensions | 84 × 174 × 52 mm |
| Model | DT4255 |
| Weight | 390 g (with batteries and holster) |
| Functions | Filter / hold / MAX/MIN/AVG display / relative display / auto-power save / USB communication (optional) |
| Included Accessories | Test lead L9207-10 / Holster / Instruction manual / 4× LR03 batteries |
| Voltage detection | Hi - AC 40 V to 600 V / Lo - AC 80 V to 600 V |
| Continuity Check | ON - ≤25 Ω / OFF - ≥245 Ω / Response time - ≥0.5 ms |
| Refresh Rate | 5 times/s (varies by function) |
| AC Current Range (Clamp Probe) | 10.00 A to 1000 A / 7 ranges / ±0.9 % rdg. ±3 dgt. (True RMS) |
| Auto AC/DC Voltage Detection | Yes |
Key Features
- Prevents short-circuit accidents with a fast-blow fuse and current-limiting resistor
- Prevents accidents with clamp-on sensor-based current measurement
- Voltage detection function
- Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
- Broad -25°C to 65°C (-13°F to 149°F) operating temperature range
- Dual display lets you check voltage and frequency simultaneously
Product Description
The Hioki DT4200 Digital Multimeter Series consists of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super-fast response rate and safety features that enhance electrical testing. The DT4255 is a digital multimeter designed for maximum safety with voltage measurement terminals that are protected by a fuse.
Available on EnvMart, these Multimeters are designed for accurate measurement of voltage, current, and resistance in electrical circuits. Hioki Multimeters offer high precision and reliability, making them essential for electrical testing, diagnostics, and maintenance applications.
