EAO 82 Series Illuminated Momentary Push Button Switch, Panel Mount, 19 mm Cutout, SPDT, Green LED, IP65/IP67 82-5151.1133



Category Push Button Switch Brand EAO Condition New

Specifications

Country of Origin	Switzerland
Brand	EAO
Length	35.5mm
IP Rating	IP65, IP67
Mount Type	Panel
Series	82
Maximum Operating Temperature	70°C
Contact Configuration	SPDT
Minimum Operating Temperature	-30°C
Panel Cutout Size	19 mm
Standards/Approvals	CCC, cUL, CB, UL
LED Colour	Green
Switch Operation	Momentary
Contact DC Voltage	240V dc
Actuator Style	Flat
Switch Contact Current	3A
Contact AC Voltage	240V ac
Legend	Blank

Key Features

Features a flat actuator style for easy operation.
Designed with IP65 and IP67 ratings for excellent dust and water resistance.
Operates at 240 V dc and 240 V ac for versatile electrical applications.
Constructed with a stainless steel lens and silver contact material for durability.
Suitable for panel mounting with a 19 mm cutout size.
Supports a switch contact current of 3 A.
Operates reliably within a temperature range of -30°C to 70°C.

Product Description

EAO 82-5151.1133 is an illuminated momentary push button switch designed for panel mounting applications. It features a precise 19 mm cutout size and a circular front dimension of 22 mm. The actuator is constructed with a stainless steel lens incorporating a green LED ring illumination for clear indication.

This switch offers a SPDT contact configuration with silver contact materials and solder terminals measuring 2.8 x 0.5 mm, ensuring high conductivity and durability. It operates efficiently under a maximum contact DC voltage of 240 V and AC voltage of 240 V, making it suitable for various electrical control circuits.

The device is rated with IP65 and IP67, providing robust protection against dust ingress and water jets, suitable for industrial and commercial environments. It functions reliably within a wide temperature range from -30°C to 70°C, ensuring performance stability in challenging conditions.

Designed according to international standards including CCC, cUL, CB, and UL, this push button switch meets rigorous safety and quality requirements. Its flat actuator style enhances user interaction by providing a smooth and accessible operating surface.

This switch is ideal for use in industrial electrical panels, automation systems, HVAC controls, and equipment where illuminated indication and reliable momentary switching are required. The compact length of 35.5 mm allows for easy integration into control panels and machinery.

Features a flat actuator style for easy operation. Designed with IP65 and IP67 ratings for excellent dust and water resistance. Operates at 240 V dc and 240 V ac for versatile electrical applications. Constructed with a stainless steel lens and silver contact material for durability.

Suitable for panel mounting with a 19 mm cutout size. Supports a switch contact current of 3 A. Operates reliably within a temperature range of -30°C to 70°C. Explore more in the Push Button Switches category at EnvMart for industrial and automation solutions.
