EAO Illuminated Momentary Push Button Switch Panel Mount 33 mm Cutout SPST Green Red LED IP66 IP67 24V dc 56-1520.0000



Category Push Button Switch Brand EAO Condition New

Specifications

Country of Origin	Switzerland
Brand	EAO
IP Rating	IP66, IP67
Mount Type	Panel
Series	56
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Switch Configuration	SPST
Minimum Operating Temperature	-45°C
Panel Cutout Size	33 mm
Standards/Approvals	CE, RoHS
LED Colour	Green, Red
Switch Operation	Momentary
Actuator Colour	Black
Contact DC Voltage	24V dc
Contact AC Voltage	24V ac

Key Features

The switch features a black actuator and is momentary in operation.
Designed with high ingress protection rating IP66 and IP67 for robust environmental resistance.
Suitable for control and emergency call systems with red and green LEDs for clear indication.
Operating temperature range is from -45°C to 85°C ensuring performance in harsh conditions.
Compact 33 mm panel cutout size facilitates easy integration into control panels.
Electronic high side switch is short circuit proof and overload protected for safety.
Ideal for use in passenger access systems, elevators, and transportation applications.
Constructed with durable plastic housing material for long service life.

Product Description

EAO 56-1520.0000 is an illuminated momentary push button switch designed for panel mounting with a 33 mm cutout size. It operates at 24 V dc with an SPST contact configuration and includes green and red LED illumination for operational indication. The black actuator enables effective manual control.

The switch provides robust performance with ingress protection ratings of IP66 and IP67, making it highly resistant to dust and water ingress. Its operating temperature range from -45°C to +85°C supports use in demanding industrial environments.

Featuring an electronic high side switch that is short circuit proof and overload protected, the switch automatically opens in case of overcurrent ensuring operator and equipment safety. This switch is not potential-free and is commonly applied in passenger access and information systems, emergency and call for aid terminals, toilet facilities on trains and buses, and lifting and moving systems.

The housing is constructed from durable plastic which adds to its longevity and resilience in harsh conditions. The product complies with CE and RoHS directives, guaranteeing conformity with European health, safety, and environmental standards.

The switch has a black actuator for tactile feedback. Momentary switch operation provides quick activation and release. Illuminated LEDs in green and red for clear visual status. 33 mm cutout panel mounting installation.

Ingress protection IP66 and IP67 for dust and water resistance. Short circuit proof and overload protected electronic high side switch. Operating temperature range from -45°C to 85°C. Plastic housing material for durability.

Suitable for industrial, transportation, emergency call, and access control applications.

This switch is a reliable solution for industrial and commercial control panels requiring illuminated push button actuation and status signaling. Browse more high-quality Push Button Switches and related electrical components on EnvMart for comprehensive automation solutions.
