Wurth Elektronik 3661 Series Pluggable Terminal Block 8-Contact 3.5 mm Pitch 1 Row 2.5kV 10A Screw Connection 691366110008

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3661 Series Pluggable Terminal Block 8-Contact 3.5 mm Pitch 1 Row 2.5kV 10A Screw Connection 691366110008

Name: Wurth Elektronik 3661 Series Pluggable Terminal Block 8-Contact 3.5 mm Pitch 1 Row 2.5kV 10A Screw Connection 691366110008
Brand: Wurth Elektronik
SKU: 421731
Price: 20.22 USD
Availability: InStock



Category Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	2.5kV
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	10A
Length	28mm
Depth	19.3mm
Width	10.4mm
Housing Material	Polyamide 66
Series	3661
Number of Rows	1
Pitch	3.5mm
Standards/Approvals	RoHS
Number of Contacts	8
Connector Gender	Male
Minimum Wire Size mm²	0.081mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screw

Key Features

Features a single row configuration for compact design.
Supports a maximum current rating of 10A suitable for moderate power applications.
Operates at a voltage rating of 2.5kV ensuring safe insulation.
Constructed with durable Polyamide 66 housing material for enhanced mechanical stability.
Uses screw connection method providing secure wiring options.
Designed with male connector gender and horizontal orientation for easy PCB assembly.
Accommodates a wire size range from 0.081 mm² to 1.31 mm² (28AWG to 16AWG).
Compliant with RoHS standards for environmental safety.

Product Description

Wurth Elektronik 691366110008 is a high-quality pluggable terminal block from the trusted 3661 series, featuring 8 contacts on a 3.5 mm pitch and a single row layout. It is engineered to provide a stable and reliable connection for electronic and electrical circuits, suitable for various industrial and commercial applications.

The terminal block handles up to 10A current and has an operating voltage rating of 2.5kV, ensuring safe and efficient power transmission. Its housing is molded from Polyamide 66, offering mechanical strength and resistance to harsh environments.

Connectivity is established through a screw connection method, which ensures a secure fastening of wires with minimum and maximum wire sizes from 0.081 mm² to 1.31 mm² (28AWG to 16AWG). The male connector gender and horizontal orientation facilitate straightforward integration on printed circuit boards.

The compact physical dimensions of 28 mm length, 19.3 mm depth, and 10.4 mm width make it appropriate for compact electronic designs. This component complies with RoHS regulations, reflecting commitment to environmental and health safety standards.

Ideal for use in industrial automation, power supply units, control systems, and other electronic assemblies, the Wurth Elektronik 3661 series terminal block enhances circuit reliability and ease of maintenance.

Features a single row configuration for compact design. Supports a maximum current rating of 10A suitable for moderate power applications. Operates at a voltage rating of 2.5kV ensuring safe insulation. Constructed with durable Polyamide 66 housing material for enhanced mechanical stability.

Uses screw connection method providing secure wiring options. Designed with male connector gender and horizontal orientation for easy PCB assembly. Accommodates a wire size range from 0.081 mm² to 1.31 mm² (28AWG to 16AWG).

Compact dimensions: 28 mm length, 19.3 mm depth, and 10.4 mm width. Compliant with RoHS standards for environmental safety. Explore more in our Power Connectors and Terminal Blocks range at EnvMart to find complementary components and products suited for your electrical and electronic projects.
