ABB 4-Pole DIN Rail Isolator Switch, IP20 IP40 Protection, 40A Switching Current, SD204 Series 2CDD284101R0040 SD204/40

Free Delivery in India | Lowest Global Shipping Charges

ABB 4-Pole DIN Rail Isolator Switch, IP20 IP40 Protection, 40A Switching Current, SD204 Series 2CDD284101R0040 SD204/40



Category Isolator Switch Brand ABB Condition New

Specifications

Country of Origin	India
Brand	ABB
Length	70mm
Model	2CDD284101R0040 SD204/40
Depth	88mm
IP Rating	IP20, IP40
Width	69mm
Mount Type	DIN Rail
Series	SD204
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Switching Current	40A
Terminal type	Screw
Electrical Phase	3
Handle Colour	Grey
Number of Poles	4
Standards/Approvals	RoHS, CE, VDE
Switching DC Voltage	131V dc
Switching AC Voltage	462V ac

Key Features

Rated switching current of 40A ensures robust load handling capacity.
IP20 and IP40 protection ratings offer dust and splash resistance for enhanced durability.
Equipped with 4 poles, compatible with three-phase electrical systems.
DIN rail mounting design facilitates easy installation in control panels.
Features auxiliary contacts and padlock compatibility for improved operation and safety.
Grey handle color for clear visibility and ergonomic operation.
Switching DC voltage rating of 131V dc and AC voltage rating of 462V ac.
Operating temperature range from -25°C to 55°C suitable for diverse environments.

Product Description

ABB 2CDD284101R0040 SD204/40 is a 4-pole DIN rail isolator switch designed for electrical and automation systems requiring safe disconnection and reliable operation. It supports a rated switching current of 40A and is suitable for three-phase applications. Its IP20 and IP40 ratings provide effective protection against dust and water splashes, ensuring durability in industrial environments.

The device features a grey handle and auxiliary contacts, enhancing control and safety. Its padlock compatibility allows for secure isolation during maintenance. The switch is equipped with screw terminal type connections, providing secure and reliable wiring.

Designed to operate over a temperature range from -25°C to 55°C, the isolator maintains performance in various environmental conditions. It meets important safety certifications including RoHS, CE, and VDE. Compact dimensions (70mm length, 69mm width, 88mm depth) allow for efficient use in control panels.

Its series SD204 design extends the System pro M compact® series with advanced safety, clear red/green "Real CPI" contact position indication, and high performance at increased voltage levels. The 35 mm² cylinder lift terminals with two openings enable secure wiring connections. The isolator integrates seamlessly with MCB accessories and busbars for cross wiring.

This isolator switch is ideal for industrial, commercial electrical installations, manufacturing plants, water treatment facilities, and HVAC systems requiring dependable isolation and load interruption.

Rated switching current of 40A. Four poles for three-phase use. IP20 and IP40 protection ratings. Padlock compatible for safe isolation. Auxiliary contacts for enhanced functionality. Complies with RoHS, CE, and VDE standards.

Real CPI red/green contact position indication. Compact and space-efficient design. Temperature range: -25°C to 55°C. Screw terminals with protection against misconnection. Explore more ABB products and Isolator Switches at EnvMart for reliable electrical solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The rated switching current of this isolator switch is 40A, ensuring robust load handling capacity.

This model has IP20 and IP40 protection ratings, offering dust and splash resistance for enhanced durability.

It features 4 poles, making it compatible with three-phase electrical systems.

The operating temperature range for this isolator switch is from -25°C to 55°C, suitable for diverse environments.

The dimensions of this isolator switch are 70mm in length, 69mm in width, and 88mm in depth.

It is equipped with screw terminal type connections, providing secure and reliable wiring.

Yes, it features auxiliary contacts for enhanced functionality and control.

This model complies with RoHS, CE, and VDE safety standards.

The switching DC voltage rating is 131V dc and the AC voltage rating is 462V ac.

It features a DIN rail mounting design, facilitating easy installation in control panels.

The handle color of this isolator switch is grey, providing clear visibility and ergonomic operation.

It is ideal for industrial, commercial electrical installations, manufacturing plants, water treatment facilities, and HVAC systems requiring dependable isolation and load interruption.
