ABB 2-Pole DIN Rail Isolator Switch, IP20, IP40, 16A, Screw Terminal, Grey Handle, SD202 Series 2CDD282101R0016 SD202/16

Free Delivery in India | Lowest Global Shipping Charges

ABB 2-Pole DIN Rail Isolator Switch, IP20, IP40, 16A, Screw Terminal, Grey Handle, SD202 Series 2CDD282101R0016 SD202/16



Category Isolator Switch Brand ABB Condition New

Specifications

Country of Origin	Italy
Brand	ABB
Length	35mm
Model	2CDD282101R0016 SD202/16
Depth	88mm
IP Rating	IP20, IP40
Width	69mm
Mount Type	DIN Rail
Series	SD202
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Switching Current	16A
Terminal type	Screw
Handle Colour	Grey
Number of Poles	2
Standards/Approvals	CE, RoHS, VDE
Switching DC Voltage	131V dc
Switching AC Voltage	462V ac

Key Features

Compact design with dimensions of 69mm width, 35mm length, and 88mm depth for space-saving installation.
Rated for 16A switching current with screw terminal connections for secure wiring.
IP20 and IP40 rated enclosure providing protection in indoor electrical installations.
Suitable for operating temperatures from -25°C to 55°C, ensuring reliable performance in varied environments.
Features grey handle and padlock compatibility to enhance safety during maintenance.
Supports switching AC voltage up to 462V AC and DC voltage up to 131V DC.
Auxiliary contacts included for status indication.
Designed to mount easily on DIN rails with the ability to install in any orientation.

Product Description

ABB 2CDD282101R0016 SD202/16 2-Pole DIN Rail Isolator Switch is designed for safe and effective isolation of electrical circuits in industrial and automation applications. Rated at 16 amps, this isolator switch provides reliable switching while offering compact dimensions of 69mm width, 35mm length, and 88mm depth suitable for installations where space is a constraint.

The device features a grey actuator handle clearly indicating switch position, enhancing operational safety. Its compatibility with padlocks allows for secure maintenance procedures to ensure machinery can be safely de-energized before service.

Constructed with screw-type terminals, the switch supports easy and safe wiring. It operates effectively at AC voltages up to 462 volts and DC voltages up to 131 volts, making it versatile for various electrical environments.

Its robust IP20 and IP40 rated housing protects internal components against ingress of solid objects and limited water splashing, making it suitable for typical indoor industrial settings. The switch supports wide operating temperatures from minus 25 to plus 55 degrees Celsius, assuring functional reliability under challenging workplace conditions.

The ABB SD202 series disconnector switch comes with auxiliary contacts that facilitate remote monitoring of switch status. With certifications such as CE, RoHS, and VDE, it complies with international standards for safety and environmental guidelines.

This isolator switch is ideal for industrial automation, electrical engineering, manufacturing equipment, and control panels. Installation is simplified with direct mounting on standard DIN rails in any position, allowing flexible panel layouts.

Compact dimensions enable space-saving installation. High current rating of 16A supports demanding applications. Protective IP20 and IP40 ratings ensure durability. Padlock compatible for enhanced operational safety. Auxiliary contacts for status signaling.

Wide temperature range operation. Certified with CE, RoHS, and VDE standards. Made in Italy, reflecting high manufacturing quality.

Choose ABB Isolator Switches for reliable circuit disconnection and maintenance safety in your electrical control system. Explore EnvMart for a wide range of switches and electrical components that help optimize industrial automation and control tasks.
