PULS CP DIN Rail Power Supply 150 V DC, 240 V AC Input, 24 V DC 5 A Output, 120 W CP5.241-S2

Free Delivery in India | Lowest Global Shipping Charges

PULS CP DIN Rail Power Supply 150 V DC, 240 V AC Input, 24 V DC 5 A Output, 120 W CP5.241-S2

Name: PULS CP DIN Rail Power Supply 150 V DC, 240 V AC Input, 24 V DC 5 A Output, 120 W CP5.241-S2
Brand: PULS
SKU: 416574
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand PULS Condition New

Specifications

Country of Origin	Czech Republic
Brand	PULS
Power	120W
Efficiency	94.3%
Height	124mm
Model	CP5.241-S2
Depth	102mm
IP Rating	IP20
Width	32mm
Series	CP
Output Current	5A
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-25°C
Number of outputs	1
Maximum Input Voltage	150, 240V dc
Electrical Phase	1
Maximum Output Voltage	24V dc
Minimum Input Voltage	100, 110V ac

Key Features

Compact size with dimensions 124 mm height, 32 mm width, and 102 mm depth.
High efficiency rating of 94.3%, reducing energy consumption and heat generation.
Wide input voltage range suitable for industrial environments from 100 to 240 V AC and maximum input voltage of 150 V DC.
Certified by CE, UL, and cULus meeting IEC and ANSI standards ensuring safety and compliance.
Operating temperature range from -25°C to 70°C for reliable performance in harsh conditions.
IP20 rated enclosure protects against solid foreign objects and suitable for indoor use.
Active power factor correction improves electrical efficiency and reduces input current distortion.

Product Description

PULS CP5.241-S2 DIN Rail Power Supply is a high-performance unit designed for industrial and commercial applications requiring reliable 24 V DC power output at 5 A and 120 W maximum power. Featuring AC/DC input compatibility ranging from 100 VAC up to 240 VAC and DC up to 150 V, it ensures versatile integration with various electrical systems.

This model emphasizes compact size with dimensions of 124 mm height, 32 mm width, and 102 mm depth, making it suitable for panel mounting on standard DIN rails. The power supply exhibits high efficiency of up to 94.3%, which minimizes energy losses and heat dissipation, thereby enhancing system longevity.

Equipped with active power factor correction and high immunity to power surges, the CP5.241-S2 supports seamless operation in industrial environments. Its output can deliver up to 5 A continuous current and can momentarily provide three times the nominal output current for 12 ms to manage motor starts or fuse tripping situations.

Designed for durability, this PULS power supply operates reliably within a temperature range of -25°C to +70°C and holds an IP20 rating, ensuring protection against dust and foreign solid objects for safe indoor enclosure use.

The unit complies with international standards such as IECEE IEC 61010-2-201, UL 508, IECEE IEC 60950-1, and carries CE marking along with UL and cULus approvals, guaranteeing safety and regulatory conformance.

Typical applications include circuit breakers, industrial automation, ITE commercial equipment, and robust motor start scenarios. The product is manufactured in the Czech Republic, assuring European-quality engineering standards.

Compact size and high efficiency preserves panel space and reduces energy costs. Wide input voltage range and surge immunity enable stable operation in complex electrical systems. Safety certifications assure compliance with global industrial safety standards.

Robust temperature range suitable for various environmental conditions. Reliable output current suitable for controlling motors and industrial devices. Explore more industrial power supply solutions in the DIN Rail Power Supplies category on EnvMart for optimized electrical system design and enhanced operational reliability.
