Hongfa Europe GMBH PCB Power Relay 24V dc Coil 10A Switching Current SPDT HF14FF/024-1ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26mm |
| Length | 29mm |
| Model | HF14FF/024-1ZTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF14FF |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1.1kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 277V |
| Coil Power | 530mW |
Key Features
- Designed for PCB mounting with PCB pin terminals for easy installation.
- Supports a coil voltage of 24V dc and offers a switching current of up to 10 amperes.
- Features silver alloy contacts providing high electrical endurance.
- Compact size with dimensions 29mm (L) x 13mm (W) x 26mm (H) for space-efficient use.
- Operates within a temperature range of -40°C to 70°C suitable for various industrial environments.
- Coil resistance of 1.1 kΩ and coil power consumption of 530mW ensure low power usage.
- Switching voltage ratings include 30V dc and up to 277V AC.
- Resistant to vibration and abrasion with a mechanical life expectancy of 10 million cycles.
Product Description
Hongfa Europe GMBH HF14FF/024-1ZTF PCB Power Relay is a high-performance single-pole double-throw (SPDT) relay designed for PCB mounting applications. It is actuated by a 24V DC coil and can handle switching currents up to 10A, making it ideal for a wide range of electrical control and automation tasks.
The relay features silver alloy contacts that ensure high electrical endurance and reliable switching performance. Its compact dimensions of 29mm length, 13mm width, and 26mm height allow excellent board space utilization in dense circuit designs.
Operating temperature range from -40°C to 70°C makes this relay suitable for industrial machinery, automotive systems, telecommunication equipment, household appliances, and other demanding environments. The coil presents a resistance of 1.1kΩ and consumes 530mW power, contributing to efficient low power operation.
The relay supports AC switching voltage up to 277V and DC switching voltage of 30V, adapting well to versatile electrical loads. It complies with RoHS environmental standards and offers high isolation voltage of 5kV between coil and contacts, protecting sensitive circuits.
This product ensures high mechanical endurance with a life expectancy of 10 million cycles, providing long-term reliability and performance in industrial applications. The design is resistant to vibration and abrasion, further supporting durability.
Designed for PCB mounting with PCB pin terminals for easy installation. 24V DC coil voltage with 10A switching current for high power handling. Silver alloy contacts for superior electrical endurance. Compact size: 29mm x 13mm x 26mm for efficient board space utilization.
Wide operating temperature: -40°C to 70°C suitable for harsh environments. Low coil power consumption of 530mW and coil resistance of 1.1 kΩ. Switching AC voltage up to 277V and DC voltage up to 30V. RoHS compliant and environmentally friendly.
High isolation voltage of 5kV between coil and contacts. Mechanical life expectancy of 10 million cycles with vibration resistance.
This power relay is extensively used in industrial automation, automotive electronics, telecommunication systems, and household appliance controls. It provides reliable switching performance with safety and durability. Explore more power relay products at EnvMart for your technical needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a switching current of up to 10 amperes.
It operates with a coil voltage of 24V DC.
The relay has compact dimensions of 29mm in length, 13mm in width, and 26mm in height.
It operates within a temperature range of -40°C to 70°C, making it suitable for various industrial environments.
This unit features a single-pole double-throw (SPDT) contact configuration.
The coil resistance is 1.1 kΩ.
The coil power consumption is 530mW, contributing to efficient low power operation.
It supports a switching voltage of up to 277V AC and 30V DC.
The contacts are made of silver alloy, which provides high electrical endurance.
Yes, it complies with RoHS environmental standards.
It has a mechanical life expectancy of 10 million cycles.
This model is designed for PCB mounting with PCB pin terminals for easy installation.
