Lite-On 2.4 V Green LED 3016 Surface CHIP LED 1206 LTST-C21KGKT

Lite-On LTST-C21KGKT is a Green LED designed for surface mount technology (SMT) in a standard 3016 CHIP LED 1206 rectangular package measuring 3.2 x 1.6 x 1.1 mm. Operating at a forward voltage of 2.4 V and capable of handling a maximum forward current of 80 mA, it offers efficient illumination with a luminous intensity of 180 mcd emitted through a clear, round lens. The LED has a viewing angle of 70 degrees, providing wide light distribution suitable for indicator, display backlighting, and optical signaling purposes.

This LED is RoHS compliant, meeting environmental safety standards, and is packaged on Tape & Reel for automated SMT assembly processes, ensuring production efficiency. It offers a maximum power dissipation of 75 mW, suitable for low power applications. The dominant wavelength at 576.5 nm produces a vivid green light, making it ideal for applications requiring clear visual signals.

Applications include electronic component displays, floor marker lighting, toys, and optical indicators within industrial, electronic, and commercial environments. The compact 3016 package type and surface mount design facilitate easy integration into modern circuit boards with minimal space requirements.

The product is manufactured in China, ensuring consistent quality and reliability. Its small footprint and standard package type make it highly compatible with all SMT assembly methods including infrared reflow soldering.

This green LED operates at a forward voltage of 2.4 volts. The LED supports a maximum forward current of 80 milliamps for reliable performance. Features a 3.2 x 1.6 mm 3016 package with a clear, round lens. Includes Tape & Reel packaging designed for automated SMT assembly.

The LED has a viewing angle of 70 degrees for broad light spread. Maximum power dissipation rating of 75 milliwatts. Luminous intensity of 180 millicandela bright green light. Compliant with RoHS environment standards. Dominant wavelength of 576.5 nm for green emission color.

Uses a 2-pin surface mount configuration. Explore our comprehensive range of LEDs and optoelectronic components on EnvMart for industrial, electronic manufacturing, and prototyping needs.
