ABB 3-Pole Panel Mount Isolator Switch IP20, 100A, 560kW OT100FT3 1SCA105023R1001

Free Delivery in India | Lowest Global Shipping Charges

ABB 3-Pole Panel Mount Isolator Switch IP20, 100A, 560kW OT100FT3 1SCA105023R1001



Category Isolator Switch Brand ABB Condition New

Specifications

Country of Origin	Finland
Brand	ABB
Length	100mm
Model	IP20
Depth	63mm
IP Rating	IP20
Width	70mm
Mount Type	Panel Mount
Series	OT
Minimum Operating Temperature	40°C
Switching Current	100A
Terminal type	Screw
Electrical Phase	3
Handle Colour	Grey
Hazardous Area Certification	ATEX
Number of Poles	3
Standards/Approvals	VDE, UL, RoHS, REACH, CSA, CE, ATEX
Switching DC Voltage	1000V dc
Switching AC Voltage	690V ac
Switching Power	560kW
Rated Insulation Voltage	750V
ABB 3-Pole Panel Mount Non-Fused Isolator Switch -, IP20, 80A, 560 kWBrand	ABB

Key Features

The device is panel mount type with a grey handle designed for enclosure or cabinet door mounting.
It supports 3 electrical poles and 3 phase operation for industrial applications.
Equipped with screw terminal type for secure electrical connections.
Operates within a temperature range of -40°C to 40°C ensuring durability in demanding environments.
Conforms to VDE, UL, RoHS, REACH, CSA, CE, and ATEX standards for safety and compliance.
The isolator switch has a rated insulation voltage of 750V and supports switching AC voltage up to 690V and DC voltage up to 1000V.
Has dimensions of 100mm length, 70mm width, and 63mm depth suitable for panel mounting.
Includes ATEX hazardous area certification, making it safe for potentially explosive environments.

Product Description

ABB OT100FT3 1SCA105023R1001 3-Pole Panel Mount Isolator Switch IP20 with 100A current rating and 560kW switching power is engineered for industrial and commercial electrical isolation applications. This panel mount device features a robust grey handle and supports 3-pole operation for 3-phase electrical circuits, allowing safe disconnection and maintenance of equipment.

The switch is designed to mount directly on enclosure or cabinet doors with a 6mm shaft compatibility, facilitating easy integration into control panels. Operable within a temperature range of -40°C to 40°C, it ensures reliability across varied environmental conditions.

Constructed to comply with international safety and environmental standards including VDE, UL, RoHS, REACH, CSA, CE, and ATEX, this isolator switch is suitable for standard and hazardous locations, particularly with its ATEX certification.

Key electrical characteristics include a rated insulation voltage of 750V, switching AC voltage capability up to 690V, and switching DC voltage up to 1000V. The switch terminals use a screw type for secure and stable wiring connections. IP20 protection rating safeguards the internal components from solid foreign objects, making it ideal for indoor use.

The device is a 3-pole, panel mount isolator switch designed for industrial electrical isolation. Rated for 100A switching current and 560kW switching power. Operating temperature range from -40°C to +40°C for robust performance.

Complies with multiple safety and environmental standards, including ATEX certification for hazardous areas. Dimensions: 100 mm length, 70 mm width, and 63 mm depth for compact panel integration. Grey handle is not included and must be ordered separately.

Manufactured in Finland ensuring premium build quality.

This ABB Isolator Switch is suited for electrical systems requiring safe isolation and disconnection during maintenance or emergency shutdowns in industries such as manufacturing, automation, electrical distribution, and control panels. Ensuring compliance and safety, it serves critical roles in residential, commercial, and industrial electrical installations.
