ABB Residual Current Circuit Breaker with Overload Protection 6A Current Rating 4-Pole 30 mA Trip 2CSR254101R1065
Specifications
| Country of Origin | Italy |
|---|---|
| Brand | ABB |
| Height | 93mm |
| Model | 2CSR254101R1065 |
| Depth | 69mm |
| Width | 105mm |
| Standards | IEC/EN 60947-2 |
| Current Rating | 6A |
| Series | DS200 |
| Terminal type | Busbar |
| Breaking Capacity | 10kA |
| Number of Poles | 4 |
| Standards/Approvals | IEC/EN 60947-2, IEC/EN 61009-1, UL/CSA |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type B |
| Reset Actuator Type | Lever |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | Type A |
| Operating Characteristic | Instantaneous |
Key Features
- Protects against overload and short-circuit currents effectively.
- Includes earth leakage protection of Type A with instantaneous tripping.
- Operates at rated AC voltage of 400V suitable for residential and industrial use.
- Complies with IEC/EN 60947-2, IEC/EN 61009-1, and UL/CSA standards.
- Features a lever reset actuator for quick and easy restoration after trips.
- Compact dimensions of 105mm width, 93mm height, and 69mm depth for space saving.
- Breaking capacity of 10kA ensures high fault current interruption capability.
- Designed to prevent indirect and direct contacts enhancing user safety.
Product Description
ABB 2CSR254101R1065 Residual Current Circuit Breaker with Overload Protection is engineered to provide comprehensive protection against overload, short circuits, and earth leakage faults in electrical installations.
This 4-pole circuit breaker offers a rated current of 6A and trip sensitivity of 30 mA, ideal for residential and light industrial applications where safety and reliability are paramount. The device conforms to internationally recognized standards including IEC/EN 60947-2 and IEC/EN 61009-1, and UL/CSA certifications, ensuring quality and compliance.
The DS200 series unit features a lever-type reset actuator for convenient manual resetting post-fault. Its instantaneous tripping characteristic and Type A residual current protection ensures rapid disconnection during earth faults, reducing risk of electric shocks.
Measuring 105mm in width, 93mm in height, and 69mm in depth, this circuit breaker fits efficiently in distribution boards with busbar-type terminals for secure connections. The maximum breaking capacity of 10kA enables safe interruption of high fault currents.
Applications include residential electrical safety, overload protection, and short circuit protection in commercial environments. This device is made in Italy, guaranteeing robust manufacturing quality.
Protects electrical circuits from overloads and short circuits effectively. Trip sensitivity of 30 mA provides enhanced earth leakage detection. Complies with multiple international safety and quality standards. Compact size allows easy installation in standard distribution panels.
Type A earth leakage protection for AC and pulsating DC residual currents. Lever reset actuator simplifies operation after fault clearance. High breaking capacity of 10kA offers reliable fault interruption. Designed for residential and commercial electrical protection.
Explore a wide range of Residual Current Circuit Breakers and electrical protection devices on EnvMart for enhanced electrical safety and compliance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6A, making it suitable for various residential and light industrial applications.
The trip sensitivity of this unit is 30 mA, providing enhanced earth leakage detection for improved safety.
It features a breaking capacity of 10kA, allowing for safe interruption of high fault currents.
The dimensions are 105mm in width, 93mm in height, and 69mm in depth, allowing for efficient installation in distribution boards.
It operates at a rated AC voltage of 400V, making it suitable for both residential and industrial use.
This model is a 4-pole circuit breaker, providing comprehensive protection for electrical circuits.
It includes a lever-type reset actuator, which allows for quick and easy restoration after a trip.
It complies with IEC/EN 60947-2, IEC/EN 61009-1, and UL/CSA standards, ensuring quality and safety.
The operating characteristic is instantaneous, allowing for rapid disconnection during earth faults.
It features busbar-type terminals for secure connections in electrical installations.
This model is manufactured in Italy, ensuring compliance with high manufacturing standards.
