ABB Residual Current Circuit Breaker with Overload Protection 20A Current Rating 3-Pole 30 mA Trip 2CSR253001R1205



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	DS200
Brand	ABB
Height	93mm
Model	2CSR253001R1205
Depth	69mm
Width	87mm
Standards	IEC/EN 60947-2
Current Rating	20A
Series	DS200
Terminal type	Busbar
Breaking Capacity	6kA
Number of Poles	3
Standards/Approvals	IEC/EN 61009-1, IEC/EN 60947-2, UL/CSA
Rated AC Voltage	400V ac
Tripping Characteristics	Type B
Reset Actuator Type	Lever
Trip Sensitivity	30mA
Earth Leakage Protection Type	AC
Operating Characteristic	Instantaneous

Key Features

Protects against overload and short-circuit currents effectively.
Designed for residential, overload, and short-circuit protection applications.
Complies with standards IEC/EN 61009-1, IEC/EN 60947-2, and UL/CSA.
Rated for 400V AC voltage with Type B tripping characteristic.
Equipped with lever reset actuator for easy operation.
Breaking capacity of 6kA ensures safety under fault conditions.
Busbar terminal type for secure electrical connections.
Earth leakage protection of AC type for sinusoidal alternating earth faults.

Product Description

ABB 2CSR253001R1205 Residual Current Circuit Breaker with Overload Protection from the DS200 series is engineered to provide comprehensive protection against overloads, short circuits, and residual earth fault currents in electrical systems. Rated for a current of 20A with a 3-pole configuration, it ensures reliable operation in residential and light industrial environments.

This breaker features a trip sensitivity of 30 mA and instantaneous operating characteristic Type B, suitable for AC earth leakage use. The device operates effectively at a rated AC voltage of 400V, supported by a breaking capacity of 6kA, providing robust safety against fault currents.

The compact design with dimensions 93mm height, 87mm width, and 69mm depth facilitates easy installation into panels using busbar terminal connections. The reset actuator is lever-type for straightforward manual resetting after tripping events.

Certified to rigorous standards IEC/EN 61009-1, IEC/EN 60947-2, and UL/CSA, this breaker ensures compliance with international safety and performance requirements. Its AC type earth leakage protection guards against indirect contact and provides additional safety measures for users.

Typical industrial use cases include residential electrical installations, short circuit and overload protection in automation systems, and supplementary earth leakage protection in commercial and light industrial electrical distribution setups.

Protects against overload and short-circuit currents effectively. Designed for residential, overload, and short-circuit protection applications. Complies with standards IEC/EN 61009-1, IEC/EN 60947-2, and UL/CSA. Rated for 400V AC voltage with Type B tripping characteristic.

Compact dimensions: 93mm height, 87mm width, and 69mm depth. Equipped with lever reset actuator for easy operation. Breaking capacity of 6kA ensures safety under fault conditions. Busbar terminal type for secure electrical connections.

Earth leakage protection of AC type for sinusoidal alternating earth faults.
