ABB Tmax XT 1SDA068588R1 XT4L 160 Ekip LSIG 100A Fixed Molded Case Circuit Breaker 1SDA068588R1 XT4L 160 Ekip LSIG 100A FF

ABB 1SDA068588R1 XT4L 160 Ekip LSIG 100A Fixed Molded Case Circuit Breaker is a high-performance electrical protection device designed to safeguard electrical systems in industrial, commercial, and automation applications. This 4-pole circuit breaker supports a rated current of 100 amperes and exceptional breaking capacity of 150 kiloamperes, ensuring reliable interruption under fault conditions. The breaker operates at a rated voltage of 690 volts AC and frequency of 50/60 Hz, compatible with varied power distribution networks.

The device features a fixed mounting and terminal configuration, providing a solid and secure connection in power distribution panels. Its compact form factor with dimensions of 160 mm height, 140 mm width, and 82.5 mm depth allows efficient space utilization in switchgear setups. The tripping mechanism is based on a solid state release integrated in ABB's advanced Ekip LSIG protection system, delivering precise and adjustable thermal, magnetic, and electronic trip characteristics for optimized circuit protection.

The circuit breaker includes a lever-type reset actuator for straightforward manual resetting after fault clearance, enhancing operational convenience. It complies with international standards IEC, CE, and RoHS, guaranteeing safety, quality, and environmental responsibility. Additionally, this model is a 'Better World' product, engineered for easy disassembly to facilitate recycling and sustainability.

Manufactured in Italy, the 1SDA068588R1 XT4L 160 offers robust construction and long service life required in demanding industrial environments such as manufacturing facilities, automation systems, electrical panels, and HVAC controls.

The product features a fixed mounting type and fixed terminals for secure installation. It supports a rated AC voltage of 690V and rated frequency of 50/60 Hz for industrial power systems. The tripping mechanism employs a solid state release type integrated in the Ekip LSIG system.

The breaker dimensions are 160 mm height, 140 mm width, and 82.5 mm depth for compact panel mounting. Reset actuator is lever type, enabling manual reset after trip conditions. Standard approvals include IEC, CE, and RoHS certifications ensuring compliance and safety.

It is a Better World product designed for disassembly contributing to sustainability. Manufactured in Italy, reflecting stringent quality standards.

This ABB Molded Case Circuit Breaker is suitable for use in electrical distribution, automation control, manufacturing plants, and commercial power panels, helping to protect circuits from overloads and short circuits with high reliability and accuracy. Explore more products in Molded Case Circuit Breakers at EnvMart to find precise electrical protection solutions.
