ABB Tmax XT Molded Case Circuit Breaker 3-Pole 80A 100 kA Breaking Capacity Fixed Mount 690V 1SDA068446R1 XT4H 160 MA 80 FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 160mm |
| Model | 1SDA068446R1 XT4H 160 MA 80 FF |
| Depth | 82.5mm |
| Width | 105mm |
| Mount Type | Fixed |
| Current Rating | 80A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 100kA |
| Number of Poles | 3 |
| Standards/Approvals | RoHS, IEC, CE |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 80 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- The breaker features a fixed mounting type for stable installation.
- Rated AC voltage is 690V and rated DC voltage is 500V.
- Thermomagnetic tripping mechanism with a magnetic release ensures safety and fast response.
- Compact dimensions with width 105mm, height 160mm, and depth 82.5mm facilitate easy panel integration.
- Complies with RoHS, IEC, and CE standards for quality and environmental safety.
- Lever-type reset actuator for quick manual reset after tripping events.
- Supports rated uninterrupted current of 160A at 50/60 Hz frequency.
- Manufactured in Italy ensuring high build quality and durability.
Product Description
ABB 1SDA068446R1 XT4H 160 MA 80 FF Molded Case Circuit Breaker is a 3-pole device engineered for industrial and commercial electrical protection applications. It supports a current rating of 80A with an impressive breaking capacity of 100 kA, ensuring protection against short circuits and overloads.
This circuit breaker features a fixed mounting configuration with front terminals that simplify connection and maintenance. Its thermomagnetic release mechanism combines thermal protection for overloads and magnetic protection for short circuit events, providing reliable and fast tripping performance.
With a rated voltage of 690V AC and 500V DC, it is well suited for varied installations in electrical distribution systems, including industrial control panels, HVAC systems, and manufacturing environments. The device operates effectively at a frequency range of 50/60 Hz and withstands impulse voltages up to 8 kV, ensuring high insulation performance.
The compact dimensions of 105mm width, 160mm height, and 82.5mm depth allow for efficient space utilization. Additionally, the lever reset actuator facilitates swift manual reset after fault clearance, reducing downtime.
This breaker complies with RoHS, IEC, and CE standards, ensuring adherence to international safety regulations and environmental considerations. It is part of ABB's Tmax XT series, known for durability and advanced protection features.
Manufactured in Italy, this product exemplifies high-quality engineering suitable for various industrial applications such as electrical distribution, manufacturing plants, and automation systems.
The breaker features a fixed mounting type for stable installation. Rated AC voltage is 690V and rated DC voltage is 500V. Thermomagnetic tripping mechanism ensures safe operation. Compact dimensions support easy panel integration.
Compliant with international standards RoHS, IEC, and CE. Lever-type reset actuator for quick manual reset. Supports rated uninterrupted current of 160A at 50/60 Hz frequency. High breaking capacity of 100 kA for robust protection.
Explore more ABB circuit breakers and electrical protection devices at EnvMart to ensure safety and performance in your electrical systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This molded case circuit breaker has a breaking capacity of 100 kA, providing robust protection against short circuits and overloads.
The rated AC voltage for this circuit breaker is 690V.
It features a thermomagnetic tripping mechanism, which combines thermal protection for overloads and magnetic protection for short circuits.
The dimensions are 105mm in width, 160mm in height, and 82.5mm in depth, allowing for efficient panel integration.
The rated DC voltage is 500V, making it suitable for various electrical distribution systems.
It is equipped with a lever-type reset actuator that allows for a quick manual reset after a tripping event.
This circuit breaker supports a rated uninterrupted current of 160A at a frequency of 50/60 Hz.
It complies with RoHS, IEC, and CE standards, ensuring adherence to international safety regulations and environmental considerations.
This molded case circuit breaker is manufactured in Italy.
This model belongs to the Tmax XT series, known for its advanced protection features.
It features a fixed mounting type, which provides stability during installation.
The rated impulse withstand voltage for this model is 8 kV, ensuring high insulation performance.
