ABB Tmax XT Molded Case Circuit Breaker 3-Pole 80A 65 kA Breaking Capacity Fixed Type 1SDA068117R1 XT4N 160 MA 80 FF

ABB 1SDA068117R1 XT4N 160 MA 80 FF Molded Case Circuit Breaker is a high-performance, fixed installation device designed to protect electrical circuits from overload and short-circuit faults. With a 3-pole configuration and an 80A current rating, it delivers a breaking capacity of 65 kA, ensuring reliable interruption of fault currents.

This breaker supports rated AC voltage of up to 690 V and DC voltage up to 500 V, making it suitable for diverse power systems. The thermomagnetic release with magnetic tripping mechanism offers fast and precise protection, while the lever reset actuator simplifies manual resetting of the device after a trip event.

Dimensioned at 160 mm height, 105 mm width, and 82.5 mm depth, the compact design facilitates integration into electrical panels and switchboards. Compliance with CE, IEC, and RoHS standards guarantees product safety, environmental responsibility, and adherence to international quality benchmarks.

Manufactured in Italy, the breaker has a Better World Claim for being designed for ease of disassembly and recycling, aligning with sustainable industry practices. It operates effectively at 50/60 Hz and withstands impulse voltages up to 8 kV, providing robust electrical tolerance in harsh industrial environments.

This molded case circuit breaker supports rated AC voltage up to 690 V and DC voltage up to 500 V. Features a thermomagnetic release tripping mechanism with a magnetic trip actuator and lever reset. Constructed to comply with CE, IEC, and RoHS standards ensuring reliability and safety.

Compact design with dimensions of 160 mm height, 105 mm width, and 82.5 mm depth. Designed and manufactured in Italy with a Better World Claim for disassembly and environmental consideration. Operating frequency range of 50/60 Hz suitable for varied industrial environments.

Provides rated impulse withstand voltage of 8 kV for robust electrical tolerance. Ideal for industrial, electrical automation, manufacturing, and commercial power distribution applications.

ABB's Tmax XT circuit breaker series is recognized for high durability and excellent protection performance in residential, commercial, and industrial electrical systems. For more electrical and automation solutions, browse the ABB brand and Molded Case Circuit Breaker category at EnvMart.
