ABB Tmax XT Molded Case Circuit Breaker 4-Pole 32A 85kA Breaking Capacity 690V AC, 500V DC 1SDA068316R1 XT4S 160 TMD 32A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 160mm |
| Model | 1SDA068316R1 XT4S 160 TMD 32A FF |
| Depth | 82.5mm |
| Width | 140mm |
| Mount Type | Fixed |
| Current Rating | 32A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 85kA |
| Number of Poles | 4 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 32 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Rated AC voltage of 690V and DC voltage of 500V for versatile electrical applications.
- Features thermal magnetic tripping mechanism ensuring reliable and safe operation.
- Complies with CE, IEC, and RoHS standards for quality and safety assurance.
- Reset actuator type lever enables simple manual operation and resetting.
- Designed with front fixed terminals for ease of wiring and installation.
- Rated impulse withstand voltage of 8kV supports high surge protection in industrial environments.
- Manufactured in Italy with a focus on sustainable design enabling easy disassembly and recycling.
Product Description
ABB 1SDA068316R1 XT4S 160 TMD 32A FF Molded Case Circuit Breaker delivers robust protection for electrical circuits in industrial, commercial, and manufacturing settings. This breaker features thermal magnetic tripping mechanism to safeguard wiring from overloads and short circuits efficiently.
Constructed for fixed mounting, the breaker offers 4 poles supporting a rated current of 32 amperes and breaking capacity up to 85 kiloamperes, suitable for high-demand applications. It operates reliably at an AC voltage rating of 690V and DC rating of 500V, making it adaptable for a wide range of power systems.
Physical dimensions of 160mm in height, 140mm in width, and 82.5mm in depth provide a compact footprint ideal for panel installations. The front fixed terminal arrangement streamlines wiring processes while maintaining secure connections.
The device adheres to CE, IEC, and RoHS standards ensuring compliance with international safety and environmental requirements. The rated impulse withstand voltage of 8kV enhances resilience against voltage spikes typically encountered in industrial power distribution systems.
Designed and manufactured in Italy, the breaker supports environmental sustainability claims including design for disassembly, facilitating end-of-life recycling. Rated AC voltage: 690V with DC voltage: 500V. Breaking capacity: 85kA providing high fault current interruption capability.
Thermal Magnetic tripping mechanism for dual protection from overload and short circuit. Compact dimensions for space-saving installations. Compliant with CE, IEC, RoHS certifications. Lever type reset actuator for manual operation.
Fixed mounting and terminal configuration. Designed for disassembly supporting environmental sustainability.
This molded case circuit breaker is ideal for industrial automation, electrical distribution boards, HVAC systems, manufacturing plants, and commercial electrical installations requiring high reliability and safety.
Explore more electrical protection devices in the Molded Case Circuit Breaker category on EnvMart for comprehensive industrial-grade solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 85 kiloamperes (kA).
It has a rated AC voltage of 690V and a rated DC voltage of 500V.
This model features 4 poles, making it suitable for various electrical applications.
It uses a thermal magnetic tripping mechanism for protection against overloads and short circuits.
The dimensions are 160mm in height, 140mm in width, and 82.5mm in depth.
This model is designed for fixed mounting, facilitating secure installation.
It complies with CE, IEC, and RoHS standards, ensuring quality and safety assurance.
The rated impulse withstand voltage is 8kV, providing protection against voltage spikes.
It features a lever type reset actuator for manual operation and resetting.
It is manufactured in Italy, with a focus on sustainable design and easy disassembly.
It is suitable for industrial automation, electrical distribution boards, HVAC systems, and commercial electrical installations.
The current rating of this molded case circuit breaker is 32 amperes (A).
