ABB Tmax XT Molded Case Circuit Breaker 4-Pole 40A 200kA Breaking Capacity Fixed Terminals 1SDA067707R1 XT2V 160 TMA 40A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 130mm |
| Model | 1SDA067707R1 XT2V 160 TMA 40A FF |
| Depth | 82.5mm |
| Width | 120mm |
| Mount Type | Fixed |
| Current Rating | 40A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 200kA |
| Number of Poles | 4 |
| Standards/Approvals | RoHS, IEC, CE |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 40 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Rated current of 40 amperes ensures effective circuit control.
- Four poles provide comprehensive three-phase power circuit protection.
- Breaking capacity of 200 kiloamperes supports high fault current interruption.
- Fixed mounting suitable for stable installations.
- Rated AC voltage up to 690 volts AC and DC voltage rating of 500 volts DC.
- Thermal magnetic tripping mechanism for overload and short circuit protection.
- Compact dimensions of 130 mm height, 120 mm width, and 82.5 mm depth.
- Lever type reset actuator for quick manual resetting.
Product Description
ABB 1SDA067707R1 XT2V 160 TMA 40A FF is a high-performance molded case circuit breaker designed for industrial, electrical automation, and commercial applications. This 4-pole breaker features fixed terminals and a thermal magnetic tripping mechanism, ideal for protecting electrical circuits against overloads and short circuits.
It supports a rated current of 40 amperes with a breaking capacity of 200 kiloamperes, capable of handling severe fault conditions safely. The unit is rated for 690 volts AC and 500 volts DC operation, making it suitable for diverse power systems.
Constructed with precision, the circuit breaker measures 130 mm in height, 120 mm in width, and 82.5 mm in depth, allowing compact panel integration. The lever reset actuator facilitates rapid resetting after trip events.
This MCCB complies with RoHS, IEC, and CE standards, ensuring it meets strict quality and safety requirements. Part of ABB’s Better World initiative, this product is designed for disassembly to support sustainability and environmental responsibility.
Rated current of 40A provides reliable circuit protection. Four poles accommodate robust three-phase systems. Breaking capacity of 200 kA ensures high fault tolerance. Fixed mounting type ensures secure installation. Thermal magnetic tripping caters to overload and short circuit.
Standards compliant with RoHS, IEC, and CE certifications. Compact size fits standard electrical panels. Lever reset actuator for easy manual operation. Environmentally conscious design enhances recyclability.
Ideal for use in industrial settings, manufacturing plants, electrical distribution boards, HVAC systems, and commercial electrical infrastructure requiring dependable circuit protection.
Explore our full range of ABB Molded Case Circuit Breakers and electrical protection devices at EnvMart for optimal system safety and compliance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated current for this molded case circuit breaker is 40 amperes.
It has a breaking capacity of 200 kiloamperes, allowing it to handle high fault currents safely.
This circuit breaker is rated for up to 690 volts AC and 500 volts DC.
This model features four poles, providing comprehensive protection for three-phase power circuits.
It employs a thermal magnetic tripping mechanism for overload and short circuit protection.
The dimensions are 130 mm in height, 120 mm in width, and 82.5 mm in depth.
It supports fixed mounting, ensuring secure installation in electrical panels.
It complies with RoHS, IEC, and CE standards, ensuring adherence to quality and safety requirements.
It features a lever type reset actuator for quick manual resetting after a trip event.
It is suitable for industrial settings, manufacturing plants, electrical distribution boards, and HVAC systems.
The rated frequency for this model is 50/60 Hz, making it versatile for different electrical systems.
The country of origin for this product is Italy.
