Samtec Pin Header 1 Contact, 2.54 mm Pitch, 1 Row, Unshrouded, Glass Filled Polyester Housing, Through TSW-101-08-T-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-101-08-T-S-RA |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a 2.54 mm (0.100") pitch for precise PCB connections.
- Constructed with glass filled polyester housing for durability.
- Single row with one phosphor bronze male contact plated with gold.
- Designed for through-hole mounting with solder termination type.
- Operates reliably within a temperature range of -55°C to 125°C.
- Supports voltage up to 550V suitable for board-to-board connector systems.
- Unshrouded style allow easy mating and inspection.
- Vertical orientation with a 0.635 mm square post contact system.
Product Description
Samtec TSW-101-08-T-S-RA is a high-quality pin header designed for electronic PCB applications requiring a 2.54 mm pitch and single-row, single-contact configuration.
The product features a phosphor bronze male contact plating with gold for reliable and low-resistance electrical connections. Its unshrouded design facilitates easy inspection and maintenance while offering through-hole mounting with solder termination, making it optimal for board-to-board interfacing.
Operating specifications include a wide temperature range from -55°C to 125°C and a voltage rating up to 550 volts, making it suitable for various industrial and commercial electronics applications. The vertical orientation and .025" (0.635 mm) square post contact system ensure mechanical robustness and alignment during assembly.
Applications for this pin header include embedded systems, industrial control boards, and custom electronic hardware requiring durable and precise connector solutions. The component complies with industry standards for reliable performance but does not carry specific formal approvals.
This product is essential in industrial, laboratory, manufacturing, and commercial electronic assemblies where secure and consistent electrical connection are critical. Samtec's TSW series supports a broad range of pin counts and configurations to meet diverse design requirements.
Features a 2.54 mm (0.100") pitch for precise PCB connections. Constructed with glass filled polyester housing for durability. Single row with one phosphor bronze male contact plated with gold. Designed for through-hole mounting with solder termination type.
Operates reliably within a temperature range of -55°C to 125°C. Supports voltage up to 550V suitable for board-to-board connector systems. Unshrouded style allow easy mating and inspection. Vertical orientation with a 0.635 mm square post contact system.
Explore the comprehensive range of PCB connectors and headers in the Electronics & Electricals category at EnvMart to find connectors optimized for your electronic assembly projects.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header features a pitch of 2.54 mm (0.100 inches), designed for precise PCB connections.
It supports a maximum voltage rating of 550V, making it suitable for board-to-board connector systems.
The pin header operates reliably within a temperature range of -55°C to 125°C.
It is constructed with a glass filled polyester housing and features a phosphor bronze male contact plated with gold.
This model is designed for through-hole mounting with a solder termination type.
It uses a .025" (0.635 mm) square post contact system for mechanical robustness and alignment during assembly.
This pin header has a single contact, configured in a single row.
The pin header is unshrouded, which allows for easy mating and inspection.
It is suitable for applications in embedded systems, industrial control boards, and custom electronic hardware.
This model has a vertical orientation.
The country of origin for this pin header is India.
