Texas Instruments Capacitance to Digital Converter 28 bit 13.3ksps 2 Channels 16-Pin WFQFN FDC2214QRGHTQ1
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 28 bit |
| Brand | Texas Instruments |
| Height | 0.75mm |
| Length | 4mm |
| Model | FDC2214QRGHTQ1 |
| Mount Type | Surface |
| Series | FDC2214-Q1 |
| Maximum Operating Temperature | 125°C |
| Package Type | WFQFN |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Conversion Rate | 13.3ksps |
| Standards/Approvals | AEC‑Q100, Automotive grade, RoHS |
| Pin Count | 16 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 2.7V |
Key Features
- High resolution 28 bit capacitive digital converter ensuring precise measurements.
- Conversion rate up to 13.3 kilo samples per second for fast data acquisition.
- Dual channel input supports two capacitive sensors simultaneously.
- Compact 16-pin WFQFN package suitable for surface mount technology.
- Wide operating voltage range from 2.7V to 3.6V for versatile power supply options.
- Operating temperature range from -40°C to 125°C meeting automotive and industrial standards.
- Complies with AEC-Q100 automotive standard ensuring reliability in harsh environments.
- RoHS compliant, promoting environmentally friendly manufacturing and disposal.
Product Description
Texas Instruments FDC2214QRGHTQ1 is a high precision capacitance to digital converter offering 28 bit resolution and a conversion rate of 13.3ksps. This device features two input channels allowing simultaneous capacitance measurements, enabling enhanced sensing solutions.
The converter is provided in a compact 16-pin WFQFN surface mount package with dimensions of 4mm by 0.75mm, suitable for incorporation into space-sensitive industrial, automotive, and consumer electronics designs.
Operating voltage requirements are minimal, supporting 2.7V to 3.6V supplies, facilitating usage in low-power applications. The device is rated for a wide operating temperature spectrum from -40°C to 125°C, aligning with automotive and industrial environmental conditions.
Designed to meet the stringent AEC-Q100 automotive qualification standard, the FDC2214QRGHTQ1 is guaranteed robust performance in demanding and harsh conditions. It is also compliant with the Restriction of Hazardous Substances (RoHS) directive, ensuring environmentally conscious manufacturing processes.
This capacitance to digital converter is ideal for industrial, automotive sensor interfacing, laboratory measurement instrumentation, and embedded systems requiring accurate capacitive sensing data.
High resolution 28 bit capacitive digital conversion. Conversion rate of 13.3ksps for real-time data. Dual-channel capability supports multiple capacitive sensors. Compact 16-pin WFQFN surface mount package. Low supply voltage from 2.7V to 3.6V.
Wide operating temperature range of -40°C to 125°C. AEC-Q100 automotive standard qualified. RoHS compliant for environmental safety. Small physical package dimensions enable compact designs.
Explore EnvMart's wide category of measuring and testing instruments for high-quality semiconductor converters and other advanced electronic components designed to meet rigorous industrial and automotive requirements.
Explore more products in our Capacitance Meter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This unit supports two channels, allowing for simultaneous capacitance measurements.
It operates within a voltage range of 2.7V to 3.6V, making it suitable for various power supply options.
The device comes in a compact 16-pin WFQFN package with dimensions of 4mm by 0.75mm.
It is rated for an operating temperature range from -40°C to 125°C.
This capacitance to digital converter is designed for surface mount technology.
It is RoHS compliant, promoting environmentally friendly manufacturing and disposal.
It belongs to the FDC2214-Q1 series.
This model is ideal for industrial, automotive sensor interfacing, laboratory measurement instrumentation, and embedded systems requiring accurate capacitive sensing data.
The FDC2214QRGHTQ1 is manufactured in India.
