ABB Residual Current Circuit Breaker with Overload Protection 25A Current Rating 2-Pole 30mA 2CSR255080R1255 DS201 B25 AC30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR255080R1255 DS201 B25 AC30
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	25A
Series	DS201
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	RoHS, IEC
Rated AC Voltage	230V ac
Tripping Characteristics	Type B
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	30mA
Earth Leakage Protection Type	AC

Key Features

Designed for single-phase circuit protection against overload and short circuit.
Trip sensitivity of 30mA ensures enhanced safety by detecting earth leakage.
Type B tripping characteristic suitable for various electrical installations.
Compact DIN rail mountable design with screw terminal connections.
High breaking capacity rated at 6kA for robust circuit safety.
Thermal magnetic tripping mechanism for precise overload response.
Complies with RoHS and IEC standards ensuring quality and safety.

Product Description

ABB residual current circuit breaker model 2CSR255080R1255 DS201 B25 AC30 is engineered for protection of single-phase electrical circuits with a 25A current rating and 2-pole configuration. This device integrates overload, short circuit, and earth leakage protection with a 30mA trip sensitivity, making it suitable for industrial, residential, and commercial electrical safety applications.

The breaker employs a thermal magnetic tripping mechanism and Type B tripping characteristics, allowing it to respond accurately to varying fault types including sinusoidal alternating earth faults, direct and indirect contacts. It features a compact design with dimensions of 85mm height, 69mm depth, and 35mm width, supporting DIN rail mounting and screw type terminals for ease of installation.

Rated AC voltage is 230V and it offers a breaking capacity of 6kA, ensuring high performance against fault currents. The product is compliant with RoHS and IEC standards which guarantee durability and adherence to international safety norms. This residual current circuit breaker is ideal for electrical installations requiring reliable earth leakage and overload protection in industrial automation, construction, and electrical distribution systems.

Designed for single-phase circuit protection against overload and short circuit. Trip sensitivity of 30mA enhances safety by detecting earth leakage currents. Type B tripping characteristic for versatile installation scenarios.

Thermal magnetic tripping mechanism ensures precise and reliable operation. DIN rail mountable with screw terminals simplifies installation. High breaking capacity of 6kA protects against severe fault currents. Compact size: 85mm height, 69mm depth, 35mm width.

Complies with RoHS and IEC standards. Explore more Residual Current Circuit Breakers and electrical safety products in the Electronics & Electricals category at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 25A, making it suitable for various electrical installations.

It features a trip sensitivity of 30mA, which enhances safety by detecting earth leakage currents.

It employs a thermal magnetic tripping mechanism, ensuring precise and reliable operation in response to overloads and faults.

The dimensions are 85mm in height, 69mm in depth, and 35mm in width, allowing for a compact installation.

This circuit breaker has a breaking capacity of 6kA, providing robust protection against fault currents.

Yes, it is designed for DIN rail mounting, which simplifies the installation process.

It is designed for single-phase electrical systems and is suitable for industrial, residential, and commercial applications.

It complies with RoHS and IEC standards, ensuring adherence to international safety norms.

This model features Type B tripping characteristics, suitable for various electrical installations including those with sinusoidal alternating earth faults.

It uses screw type terminals, facilitating secure connections during installation.

The rated AC voltage for this model is 230V, making it compatible with standard electrical systems.

This circuit breaker belongs to the System Pro M Compact range, designed for effective circuit protection.
