TDK EMC Filter B84143A0080R021 80 A 760V AC 50Hz 60Hz Terminal Block 3 Phase
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 141mm |
| Length | 300mm |
| Model | B84143A0080R021 |
| Depth | 171mm |
| Operating Frequency | 50, 60Hz |
| Series | B84143A*R021 |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 80A |
| Number of Phases | 3 |
| Leakage Current | 4.2mA |
| Maximum Voltage | 760V ac |
| Standards/Approvals | RoHS |
| Termination Style | Terminal Block |
Key Features
- Supports a maximum current of 80 amperes.
- Operates efficiently at 760 volts AC and frequencies of 50Hz and 60Hz.
- Features terminal block termination style suitable for 3-phase connections.
- Compact design with dimensions of 300mm length, 141mm height and 171mm depth.
- Optimized leakage current of 4.2 mA ensures minimal energy loss.
- Wide operating temperature range from -25°C to 100°C.
- Compliant with RoHS standards for environmentally safe use.
- Ideal for frequency converters in motor drives, elevators, pumps, traction and conveyor systems.
Product Description
TDK B84143A0080R021 EMC Filter is engineered for demanding industrial applications requiring reliable electromagnetic compatibility and noise reduction. This 3-phase filter supports a maximum current of 80 A and operates at voltages up to 760V AC across 50Hz and 60Hz frequencies.
The device features a terminal block termination style for secure and straightforward installation in power line configurations. Its compact dimensions of 300mm length, 141mm height, and 171mm depth make it a space-saving solution optimized for long motor cables and operation under full load conditions.
With an optimized leakage current of 4.2 mA and high insertion loss characteristics, this filter effectively minimizes electromagnetic interference ensuring smooth and stable performance in frequency converters for motor drives. Typical applications include elevators, pumps, traction systems, conveyor systems, HVAC systems, wind farms, and power supplies.
The product is RoHS compliant and manufactured in Hungary, ensuring adherence to environmental and safety standards. Its operational temperature ranges from -25°C up to 100°C, maintaining performance under varied industrial environments.
Supports maximum current of 80 amperes. Operates at 760V AC and frequencies of 50Hz and 60Hz. Terminal Block termination for 3-phase power lines. Compact form factor, 300mm x 141mm x 171mm. Optimized leakage current of 4.2 mA.
Wide operating temperature range from -25°C to 100°C. RoHS compliant ensuring environmental safety. Optimized for use in frequency converters and motor drives. Suitable for HVAC, elevators, pumps, and wind farm applications.
This EMC filter is a reliable component for industrial, manufacturing, HVAC, and power conditioning systems requiring robust noise suppression and power quality improvement. Explore more in the Power Line Filters category on EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TDK B84143A0080R021 EMC filter supports a maximum current of 80 amperes.
It operates efficiently at a maximum voltage of 760V AC.
This unit is compatible with operating frequencies of 50Hz and 60Hz.
The filter features a terminal block termination style suitable for 3-phase connections.
The compact dimensions of this model are 300mm in length, 141mm in height, and 171mm in depth.
It has an optimized leakage current of 4.2 mA, ensuring minimal energy loss.
The operating temperature range is from -25°C to 100°C.
Yes, this filter is RoHS compliant, ensuring it meets environmental safety standards.
Typical applications include frequency converters for motor drives, elevators, pumps, and conveyor systems.
The TDK B84143A0080R021 EMC filter is manufactured in Hungary.
This EMC filter is part of the B84143A*R021 series.
The filter is designed with high insertion loss characteristics to effectively minimize electromagnetic interference.
