Bourns GMOV Varistor 4 pF Capacitance 10000 A Clamping 875 V Disc Through Hole GMOV-20D301K

Free Delivery in India | Lowest Global Shipping Charges

Bourns GMOV Varistor 4 pF Capacitance 10000 A Clamping 875 V Disc Through Hole GMOV-20D301K

Name: Bourns GMOV Varistor 4 pF Capacitance 10000 A Clamping 875 V Disc Through Hole GMOV-20D301K
Brand: BOURNS
SKU: 400347
Price: 2.41 USD
Availability: InStock



Category Varistor Brand BOURNS Condition New

Specifications

Country of Origin	China
Diameter	23mm
Brand	Bourns
Material	Metal
THICKNESS	9mm
Model	GMOV-20D301K
Packaging	Bulk
Mount Type	Through Hole
Series	GMOV
Maximum Operating Temperature	85°C
Capacitance	4pF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	415V dc
Standards/Approvals	UL 1449 4th Edition, RoHS
Package/Case	Disc
Pin Count	2
Termination Style	Radial
Lead Pitch	10mm
Maximum AC Voltage	320V ac
Clamping Voltage VC	875V
Clamping Current	10000A
Varistor Voltage	300 Vrms, 385 V dc

Key Features

This varistor features a hybrid design for low leakage current.
It provides bidirectional surge protection with a maximum operating temperature of 85°C.
Through hole mounting and radial termination style enable easy PCB installation.
Material construction is metal with a disc package/case of 23 mm diameter and 9 mm thickness.
Conforms to UL 1449 4th Edition and RoHS standards.
Suitable for AC voltage max 320 V and DC max voltage 415 V applications.
Operates reliably in temperature range from -40°C to 85°C.
Pin count is 2 with a 10 mm lead pitch for secure connections.

Product Description

Bourns GMOV-20D301K varistor is a high-performance disc-shaped surge protection component. It features a capacitance of 4 pF and is designed for electrical protection in applications requiring a clamping current up to 10000 A at 875 V voltage. This varistor operates at voltages of 300 Vrms AC and 385 V DC, ensuring robust surge suppression for electronic circuits.

Constructed with metal material and a hybrid design, the varistor offers low leakage current and bidirectional protection, making it suitable for use in industrial, electronic components, and power systems requiring robust passive components for surge mitigation. Its through-hole mounting with radial termination style facilitates easy and secure assembly onto printed circuit boards.

The varistor has a diameter of 23 mm, thickness of 9 mm, and pin lead pitch of 10 mm, making it compact yet powerful. It is compliant with UL 1449 4th Edition and RoHS standards, supporting eco-friendly manufacturing and safety requirements. Operating temperature ranges from -40°C to 85°C, enabling stable performance in various environmental conditions.

Applications span use in electronic circuit protection, power supply safeguarding, and general surge protection across industrial and commercial electronics. The product is made in China and packaged in bulk form to support production efficiency.

Hybrid design for low leakage current. Bidirectional surge protection. Metal material construction with disc package. Compliant with UL 1449 4th Edition and RoHS standards. Through hole mount with radial termination style.

Operates from -40°C to 85°C temperature range. Supports voltages of 320 V AC max and 415 V DC max. Lead pitch of 10 mm with 2 pins. For a comprehensive selection of high-quality Varistors and surge protection components, explore the Bourns product line and related electronic components at EnvMart.
