ABB Residual Current Circuit Breaker with Overload Protection 10A Current Rating 1-Pole 30 mA Trip DS-ARC1 M C10 A30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	DS-ARC1 M C10 A30
Depth	85mm
Width	52.5mm
Mount Type	DIN Rail
Current Rating	10A
Series	DS-ARC1
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	RoHS, IEC
Rated AC Voltage	240V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Supply possible both from top and bottom side	double slots available for connection with cables and busbars

Key Features

Provides integrated arc fault detection and overcurrent protection for enhanced electrical safety.
Compact 3-module width design with easy cross-wiring and DIN rail mounting.
Compatible with System pro M compact® busbars for seamless installation.
Equipped with LED indicators and test buttons for easy troubleshooting and verification.
Double slots allow supply connection from top and bottom with cables or busbars.
Breaking capacity rated at 10 kA ensures robust fault clearance.
Thermal magnetic tripping mechanism delivers reliable overload and short-circuit protection.
Manufactured in Italy, RoHS and IEC compliant for quality assurance.

Product Description

ABB DS-ARC1 M C10 A30 residual current circuit breaker with overload protection features a 10 ampere current rating and single pole (1P) design suitable for residential and commercial electrical applications. Operating at a rated AC voltage of 240V, this device integrates residual current detection with a thermal magnetic tripping mechanism providing robust protection against arc faults, overcurrent, and earth leakage.

Engineered within the System pro M Compact series, the breaker is designed with a compact three-module width ensuring efficient use of panel space. Installation is simplified by easy cross-wiring capabilities and compatibility with System pro M compact® busbars, facilitating swift integration without additional cables.

The product includes LED indicators for fault diagnostics and two test buttons to verify correct functioning of both the Arc Fault Detection Device (AFDD) and residual current device (RCD) components. Supply can be connected from both top and bottom sides via double slots designed for cables and busbars, enhancing flexibility in wiring configurations.

With a breaking capacity of 10 kA, the DS-ARC1 M C10 A30 is engineered to handle high fault currents safely and reliably. The toggle switch actuator provides a clear manual reset option after tripping events. This residual current circuit breaker complies with RoHS and IEC standards, assuring quality and environmental responsibility.

Dimensions measure 85 mm in height and depth and 52.5 mm in width, with screw-type terminals for secure connections. Manufactured in Italy, it meets stringent quality benchmarks for electrical safety devices.

This circuit breaker is ideal for use in industrial, commercial, and residential electrical distribution panels requiring reliable earth leakage and overcurrent protection, combining arc fault detection functionality within compact dimensions.

Provides integrated arc fault detection and overcurrent protection for enhanced electrical safety. Compact 3-module width design with easy cross-wiring and DIN rail mounting. Compatible with System pro M compact® busbars for seamless installation.

Equipped with LED indicators and test buttons for easy troubleshooting and verification. Double slots allow supply connection from top and bottom with cables or busbars. Breaking capacity rated at 10 kA ensures robust fault clearance.

Thermal magnetic tripping mechanism delivers reliable overload and short-circuit protection. Manufactured in Italy, RoHS and IEC compliant for quality assurance.

Explore EnvMart’s comprehensive range of Residual Current Circuit Breakers and electrical protection devices to find the right solutions for your electrical safety and automation requirements.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 10A, making it suitable for various residential and commercial electrical applications.

The breaking capacity of the DS-ARC1 M C10 A30 is rated at 10 kA, ensuring robust fault clearance in case of electrical faults.

This unit measures 85 mm in height and depth, and 52.5 mm in width, allowing for efficient use of panel space.

The thermal magnetic tripping mechanism provides reliable overload and short-circuit protection by detecting excessive current levels and tripping the circuit accordingly.

It is designed for DIN rail mounting, which facilitates easy installation in electrical distribution panels.

The trip sensitivity is set at 30 mA, providing effective earth leakage protection for electrical systems.

Yes, it features double slots that allow for supply connections from both the top and bottom, enhancing wiring flexibility.

This model complies with RoHS and IEC standards, ensuring quality and environmental responsibility in its manufacturing.

The rated AC voltage for the DS-ARC1 M C10 A30 is 240V, making it suitable for standard electrical systems.

It provides Type A earth leakage protection, which is effective for detecting both AC and pulsating DC residual currents.

The circuit breaker is equipped with LED indicators and two test buttons that facilitate easy troubleshooting and verification of its functions.

This model is part of the System Pro M Compact series, known for its compact design and efficient use of space in electrical panels.
