Siemens Residual Current Circuit Breaker with Overload Protection 10A 2-Pole 30 mA Trip Sensitivity DIN Rail 5SU1356-6KK10

Siemens 5SU1356-6KK10 Residual Current Circuit Breaker with Overload Protection is a critical electrical safety device designed for effective fault protection in various automation and electrical installations. This device provides a 10A current rating and operates at 230V AC with a 2-pole configuration to safeguard phase and neutral conductors.

Featuring a trip sensitivity of 30 mA and Type B tripping characteristics, it ensures rapid disconnection during earth faults, protecting personnel and equipment. The breaker offers a substantial breaking capacity of 15 kA, capable of interrupting serious fault currents instantly.

The device mounts on standard DIN rails, allowing easy integration into electrical panels and automation control systems. Screw terminals provide secure and reliable conductor connections. It is constructed with halogen-free and silicon-free materials, enhancing environmental safety and sustainability.

Compact and robust, the breaker measures 90 mm in height, 77 mm in depth, and 36 mm in width, making it suitable for installations with space constraints. Certified with CE standards and manufactured in Romania, it guarantees premium quality and compliance with international safety norms.

This Residual Current Circuit Breaker is ideal for residential, commercial, and industrial applications, including electrical distribution boards and automation systems where precise earth fault protection is vital. Its design supports ambient temperature operation ranging from -25°C to 55°C, offering versatility across diverse environmental conditions.

Provides instantaneous tripping for enhanced electrical safety. Equipped with type B tripping characteristics for sensitive fault detection. Has a breaking capacity rated at 15 kA for robust fault clearing. Mounts easily on DIN rails for flexible installation.

Features screw terminal connections ensuring secure wiring. Halogen-free and silicon-free materials for improved environmental safety. Compact dimensions of 90mm height, 77mm depth, and 36mm width. Certified with CE standards ensuring quality compliance.

Designed for use in residential, commercial, and industrial electrical distribution systems. Manufactured in Romania, ensuring adherence to high production standards. Explore the Siemens category on EnvMart for a wide range of high-quality electrical protection devices.
