Amphenol ICC CD 26 Way Right Angle 2.285 mm Pitch Plug-in D-Sub Connector, Female, Screw Mount ICD26S13E4GV00LF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 300V |
| Brand | Amphenol ICC |
| Orientation | Right Angle |
| Current | 3A |
| Model | ICD26S13E4GV00LF |
| Mount Type | Plug-in |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | CD |
| Mounting Hardware | Screw |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.285mm |
| Contact Plating | Tin, Nickel, Gold |
| Number of Contacts | 26 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | High Density |
| D-Sub Shell Size | A |
Key Features
- Features 26 contacts designed for reliable data transmission.
- Supports a maximum current of 3A at 300V operating voltage.
- Right angle orientation with plug-in mount type for ease of installation.
- Constructed with thermoplastic housing and copper alloy contacts plated with tin, nickel, and gold for durability.
- Operating temperature range from -55°C to 125°C ensures suitability in harsh environments.
- Termination by solder with female connector gender and screw mounting hardware.
- High-density D-sub shell size A complies with industry standards.
- RoHS compliant and manufactured in India to ensure quality standards.
Product Description
Amphenol ICC ICD26S13E4GV00LF is a high-density 26 Way Right Angle Plug-in D-Sub Connector designed for robust electronic interconnect solutions. With a precise 2.285 mm pitch, this connector ensures reliable signal transmission in compact applications.
The connector features a female, solder termination type with screw mounting, making it suitable for secure PCB or panel installations in demanding industrial, telecommunications, and computing applications.
Constructed with a thermoplastic housing and copper alloy contacts plated with tin, nickel, and gold, it offers enhanced durability, corrosion resistance, and long-term performance. This connector supports an operating voltage of 300V and a maximum current rating of 3A, making it ideal for power and data hybrid applications.
With an operating temperature range from -55°C to 125°C, it is engineered to withstand challenging environments, suitable for industrial, networking, and electronic manufacturing uses.
The shell size A and right angle orientation allow for high-density board layouts and efficient space utilization. This model is RoHS compliant and manufactured in India, ensuring eco-friendly standards and consistent production quality.
Features 26 contacts designed for reliable data transmission. Supports a maximum current of 3A at 300V operating voltage. Right angle orientation with plug-in mount type for ease of installation. Constructed with thermoplastic housing and copper alloy contacts plated with tin, nickel, and gold for durability.
Operating temperature range from -55°C to 125°C ensures suitability in harsh environments. Termination by solder with female connector gender and screw mounting hardware. High-density D-sub shell size A complies with industry standards.
RoHS compliant and manufactured in India to ensure quality standards.
This connector is ideal for electronic components, power distribution, telecommunications, networking hardware, and computing systems where compact and durable D-sub interconnection is required.
Explore a wide range of connectors and electronic components at EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 3A.
It operates at a maximum voltage of 300V.
The pitch size of this connector is 2.285 mm.
It has an operating temperature range from -55°C to 125°C.
The housing is made of thermoplastic, and the contacts are copper alloy plated with tin, nickel, and gold.
It features a solder termination type with a female connector gender.
This model uses a plug-in mount type with screw mounting hardware.
It is a high-density D-sub shell size A, complying with industry standards.
It is ideal for electronic components, power distribution, telecommunications, networking hardware, and computing systems.
Yes, it is RoHS compliant, ensuring it meets eco-friendly standards.
It is manufactured in India, ensuring quality standards.
The connector has a female contact gender.
