RS PRO 1384 Temperature Data Logger USB Interface 4 Channel ±0.05% Accuracy Taiwan, Province Of China 123-2235

Free Delivery in India | Lowest Global Shipping Charges

RS PRO 1384 Temperature Data Logger USB Interface 4 Channel ±0.05% Accuracy Taiwan, Province Of China 123-2235

Name: RS PRO 1384 Temperature Data Logger USB Interface 4 Channel ±0.05% Accuracy Taiwan, Province Of China 123-2235
Brand: RS PRO
SKU: 397311
Price: 20.22 USD
Availability: InStock



Category Data Logger Brand RS PRO Condition New

Specifications

Country of Origin	Taiwan
Accuracy	±0.05 (B) %, ±0.05 (E) %, ±0.05 (J) %, ±0.05 (K) %, ±0.05 (R/S) %, ±0.1 (C) %, ±0.1 (L) %, ±0.1 (N) %, ±0.1 (T) %, ±0.1 (U) %
Display Type	LCD
Display	4 input functions for temperature display
Brand	RS PRO
Dimensions	187 mm Length x 73 mm Width x 53 mm Height
Battery Life	55h
Battery type	AA
Height	187mm
Length	73mm
Model	123-2235
Gross Weight	405 g approximately (with batteries)
Width	53mm
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
Interfaces	USB interface - provides communication between the data logger and your PC, measurements can be downloaded for future analysis
Number Of Channels	4
Measurement Parameters	Temperature
Interface Type	USB
RS PRO 1365 Data Logger, RS232, USBBrand	RS PRO

Key Features

The data logger supports K, J, E, T, R, S, N, L, U, B, and C-type thermocouples.
It features isolated input protection of 350 Vp-p between inputs to ensure safety and data integrity.
The device includes programmable high and low alarms for all four temperature inputs.
It offers an LCD display showing MAX, MIN, and MAX - MIN values for each input.
Memory capacity includes 512 KB auto data logging, with the ability to store up to 99 dataset readings.
The compact dimensions are 187 mm length x 73 mm width x 53 mm height, with a weight of approximately 405 grams including batteries.
Ideal for industrial, laboratory, HVAC, environmental monitoring, and agricultural applications.
USB interface allows easy data transfer to PC for detailed analysis and record keeping.

Product Description

RS PRO 123-2235 is a highly accurate temperature data logger featuring a USB interface and four input channels for temperature measurement using various thermocouple types. Manufactured in Taiwan, Province Of China, this device is engineered to provide precise digital thermometry with an accuracy of ±0.05% across multiple thermocouple configurations including types K, J, E, T, R, S, N, L, U, B, and C.

Equipped with isolated input protection of 350 V peak-to-peak between any two inputs, the data logger ensures reliable and safe operation in industrial environments. Its programmable high and low alarms function across all four channels, providing timely indication of temperature deviations.

The device features an LCD display capable of showing maximum, minimum, and differential values per input channel. It stores data automatically in its 512 KB memory, capable of holding up to 99 sets of measurements for later review.

Powered by AA batteries, this data logger offers around 55 hours of battery life, suitable for unattended monitoring over extended periods. Its compact size and lightweight build (187 x 73 x 53 mm, 405 g) enable easy deployment in environmental, agricultural, food production, HVAC, healthcare, warehousing, and laboratory applications where continuous monitoring is critical.

The device supports multiple thermocouple types for versatile temperature monitoring. Isolated input protection safeguards the logger from voltage spikes. Alarm programmability ensures operation within set safety tolerances.

Memory capacity enables extensive data collection for thorough analysis. USB connectivity simplifies data downloading and integration with PC software. LCD display facilitates onsite monitoring of temperature trends. Batteries supplied enable immediate, standalone operation.

This RS PRO Data Logger is intended for professional use in industrial and laboratory measurement contexts, providing secure, accurate, and reliable temperature recording. Available through EnvMart for users requiring precise data acquisition solutions.
