ABB F404 Series Residual Current Circuit Breaker 63A 3-Pole 30mA Type A 1kA Breaking 2CCF544110E0630 - F404A-63/0.03, 2CC
Specifications
| Country of Origin | Switzerland |
|---|---|
| Range | SmiSSline |
| Brand | ABB |
| Height | 91mm |
| Model | 2CCF544110E0630 - F404A-63/0.03, 2CC |
| Depth | 75mm |
| Width | 36mm |
| Mount Type | Conductor Bar Mount |
| Current Rating | 63A |
| Series | F404 |
| Terminal type | Screw |
| Breaking Capacity | 1kA |
| Number of Poles | 3 |
| Standards/Approvals | REACH, UL 1053, RoHS, IEC/EN 61008 |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type A |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Break Time | Instantaneous |
| Earth Leakage Protection Type | Type A |
Key Features
- Rated current of 63A ensures optimal protection for electrical circuits.
- Three-pole design suitable for three-phase power systems.
- Trip sensitivity of 30mA Type A for sensitive AC and pulsating DC fault detection.
- Breaking capacity of 1kA enhances safety against short circuits.
- Compact dimensions with 36mm width, 91mm height, and 75mm depth for easy installation.
- Screw terminal type ensures secure conductor connections.
- Mount type supports conductor bar mounting installation.
- Includes toggle switch reset actuator for user-friendly operation.
Product Description
ABB 2CCF544110E0630 - F404A-63/0.03, 2CC Residual Current Circuit Breaker is a high-quality electrical protection device designed to detect earth leakage currents and provide rapid disconnection of faulty circuits. With a rated current of 63A and a three-pole configuration, it is suitable for electrical installations requiring robust protective measures to mitigate electrical shock hazards and fire risks.
This RCCB model features a Type A tripping characteristic with 30mA trip sensitivity, enabling detection of AC and pulsating DC leakage currents. The breaking capacity of 1kA ensures the breaker can safely interrupt short-circuit faults up to this rating, protecting wiring and connected equipment.
Designed for conductor bar mount installation, it offers a compact form factor with dimensions of 36mm width, 91mm height, and 75mm depth, minimizing panel space usage. The unit includes screw terminals for secure wiring and a toggle switch for convenient manual reset. Its instantaneous break time ensures quick fault clearance to limit damage and enhance safety.
Compliance with standards REACH, UL 1053, RoHS, and IEC/EN 61008 guarantees the breaker meets stringent quality, environmental, and safety requirements. Manufactured in Switzerland, this Residual Current Circuit Breaker is ideal for residential, commercial, and light industrial applications requiring earth leakage protection at 400V AC supply voltage.
Rated current of 63A for reliable circuit protection. Three-pole design for three-phase systems. Type A trip sensitivity of 30mA for AC and pulsating DC leakages. Breaking capacity of 1kA for short circuit endurance. Compact size with 36mm width, 91mm height, and 75mm depth.
Secure screw terminal connections. Toggle switch for easy manual reset. Instantaneous break time for rapid fault disconnection. Meets REACH, UL 1053, RoHS, IEC/EN 61008 standards. Conductor bar mount suitable installation.
Suitable for use in various electrical distribution boards in residential and commercial buildings. Provides effective earth leakage protection to enhance electrical safety for occupants and property. Explore more ABB electrical protection products and related circuit breakers on EnvMart for comprehensive electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated current of this model is 63A, providing optimal protection for electrical circuits.
It features Type A tripping characteristics with a trip sensitivity of 30mA, suitable for detecting AC and pulsating DC leakage currents.
The breaking capacity of this unit is 1kA, which allows it to safely interrupt short-circuit faults.
This model has compact dimensions of 36mm width, 91mm height, and 75mm depth, making it suitable for installations with limited space.
It supports conductor bar mounting installation, ensuring secure placement within electrical distribution boards.
Wiring is connected via screw terminals, which provide secure connections for conductors.
It includes a toggle switch reset actuator for user-friendly manual operation.
This model complies with REACH, UL 1053, RoHS, and IEC/EN 61008 standards, ensuring it meets quality and safety requirements.
The rated AC voltage for this RCCB is 400V, making it suitable for various electrical installations.
It provides Type A earth leakage protection, which is effective for detecting both AC and pulsating DC leakages.
It is suitable for residential, commercial, and light industrial applications requiring earth leakage protection.
This model is manufactured in Switzerland, ensuring adherence to stringent quality standards.
