KEMET R60 Film Capacitor, 330 nF ±5 % 100 V DC 63 V AC Through Hole Mount R60EF3330AA6AJ

KEMET R60EF3330AA6AJ Film Capacitor is a high-quality polyester film capacitor designed for reliable performance in electronic circuits. It features a capacitance of 330 nF with a tight tolerance of ±5 %, rated for 100 V DC and 63 V AC, making it versatile for various low voltage electronic applications.

This capacitor is mounted using through-hole leads with a 10 mm lead pitch and 25 mm lead length, allowing for easy installation on printed circuit boards. The robust self-extinguishing plastic case protects the capacitor winding and meets UL 94V - 0 safety standards.

Operating temperature range extends from -55°C to +105°C, enabling dependable function across demanding environments. With a dissipation factor of 1 %, the capacitor minimizes energy loss during operation.

The compact dimensions of 13 mm length, 9 mm height, and 4 mm width allow integration into tight spaces typical in automotive and industrial electronics. Its applications include blocking, coupling, decoupling, bypassing, and oscillator circuits.

The R60 series offers capacitors with voltage ratings up to 1000 V DC and capacitance up to 150 µF, making this part suitable for a broad range of power electronic devices. The bulk packaging format facilitates efficient assembly and production workflows.

This film capacitor uses a through-hole mounting style for secure PCB attachment. Rated for a maximum operating temperature of 105°C and minimum of -55°C. Features a lead pitch of 10 mm and lead length of 25 mm with 0.6 mm lead diameter.

The capacitor body dimensions are compact with a width of 4 mm, height of 9 mm, and length of 13 mm. It offers a dissipation factor of 1 % and is available in bulk packaging for efficient usage. Suitable for applications including coupling, timing, bypassing, blocking, and oscillator functions.

Constructed with a self-extinguishing plastic case meeting UL 94V - 0 standards for safety. The capacitor is part of the R60 series with voltage range options from 50 to 1000 V DC and capacitance range from 0.001 µF to 150 µF.

This product is ideal for use in industrial, electronic manufacturing, automotive electronics, HVAC systems, and laboratory equipment where reliable and stable capacitance is crucial.
