Texas Instruments RS-422 Line Transmitter 3 State Differential Input Surface Mount SOIC 16 Pin AM26C31ID

Texas Instruments AM26C31ID is a high-performance RS-422 Line Transmitter featuring a 3 state output and differential input designed for robust industrial and electronic communication applications. The device comes in a 16-pin SOIC surface mount package, ideal for space-constrained PCB layouts.

This line driver IC belongs to the AM26C31 series and implements a BiCMOS logic family, combining the benefits of bipolar and CMOS technologies to achieve high speed and low power consumption. The transmitter operates from a supply voltage range of 4.5 to 5.5 volts, accommodating typical 5V powered systems.

It is built to withstand a wide operating temperature range from -40°C to 85°C, making it reliable for harsh industrial environments. With a maximum propagation delay of 12ns at the specified load capacitance, it supports fast data-rate signal transmissions essential in RS-422 communication protocols.

The device features a maximum output current of ±20mA and a low current supply of 3mA, optimizing power efficiency while maintaining signal integrity. The package dimensions of 10mm length, 6.2mm width, and a 1.75mm height ensure compatibility with compact design requirements.

Manufactured in Mexico, the AM26C31ID is not automotive graded but is suitable for a broad range of industrial, laboratory, and electronic communication systems requiring reliable line transmission.

Utilizes BiCMOS logic family for efficient performance. Operates with a supply voltage range from 4.5V to 5.5V. Maximum operating temperature up to 85°C and minimum of -40°C. Fan out differential input to improve line driving capabilities in RS-422 applications.

Compact package dimensions: 10mm length, 6.2mm width, and 1.75mm height SOIC package. Low supply current consumption at 3mA for power efficiency. Maximum propagation delay time at load capacitance is 12ns for fast signal transmission.

Designed to meet standard industrial environmental and electrical parameters without automotive qualification. Manufactured in Mexico ensuring quality production standards.

This product is widely used in industrial electronics, communication systems, instrumentation, and automation applications where differential line driving is critical. Explore similar semiconductor line interface devices to find complementary components for your design needs on EnvMart.
