Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 63A, Type C, 240V AC, 48V DC, 10kA Breaking Capacity 278567 FAZ-C63/1
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278567 FAZ-C63/1 |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 63A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
Key Features
- Rated current of 63 amperes suitable for various electrical systems.
- Type C tripping characteristic designed for moderate inrush currents.
- Breaking capacity of 10 kiloamperes to safely interrupt fault currents.
- Compact DIN rail mount for efficient panel installation.
- Screw terminal type guarantees secure wiring connections.
- Thermal magnetic tripping mechanism combines thermal and electromagnetic protection.
- Toggle switch reset actuator with clear contact position indication.
- IP20 rated for finger protection and basic environmental resistance.
Product Description
Eaton 278567 FAZ-C63/1 Miniature Circuit Breaker is a high-quality device from the xEffect FAZ series designed for protecting electrical circuits against overloads and short circuits. It incorporates a thermal magnetic tripping mechanism that provides fast and reliable interruption of fault conditions, enhancing electrical safety.
This 1-pole MCB features a rated current of 63A and supports both AC and DC voltages rated at 240V AC and 48V DC respectively. The device’s breaking capacity is rated at 10kA, ensuring robust protection against high fault currents in industrial, commercial, and residential electrical distribution boards.
The FAZ series is optimized for easy DIN rail installation with a slim 17.5mm module width per pole which saves space within control panels. It includes a screw terminal type for secure electrical connections and a toggle switch reset actuator that clearly shows contact position for ease of operation. The IP20 rating offers finger protection, making it suitable for indoor electrical enclosures.
These miniature circuit breakers are widely used in various industrial control circuits and electrical distribution systems, protecting sensitive equipment and wiring from damage due to short circuits and overloads. Eaton’s FAZ range complies with IEC 60947-2 and other international standards, ensuring high reliability and safety.
Rated current of 63 amperes for electrical protection. Type C tripping characteristics suitable for moderate surge currents. Supports 240V AC and 48V DC voltages. 10kA breaking capacity for high fault current interruption.
DIN rail mounting for ease of installation. Screw terminal connections provide security and reliability. Thermal magnetic tripping mechanism for comprehensive protection. Toggle switch reset actuator with status indication.
Compact 17.5mm width per pole saves panel space. IP20 rated for finger safety in indoor environments. Explore more Eaton Miniature Circuit Breakers and electrical protection devices at EnvMart for your industrial and commercial electrical safety needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated current of this model is 63 amperes, suitable for various electrical systems.
It features a Type C tripping characteristic, designed for moderate inrush currents.
The breaking capacity is rated at 10 kiloamperes, ensuring safe interruption of fault currents.
It supports both 240V AC and 48V DC voltages.
It is designed for DIN rail mounting, which facilitates efficient installation in control panels.
It uses screw terminals for secure wiring connections.
The width of this unit is 66mm, and it has a compact design that saves space.
This circuit breaker has an IP20 rating, providing finger protection and basic environmental resistance.
It incorporates a thermal magnetic tripping mechanism that provides both thermal and electromagnetic protection.
The depth of this model is 80mm.
The break time is instantaneous, allowing for quick interruption of fault conditions.
The country of origin for this circuit breaker is India.
